P21-012AR

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
P21-012AR CTC Parker Automation P2 PowerStation
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS IN 1-2 WEEKS

Sell Surplus: Have a P21-012AR to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: P21-012AR
  • SKU: CPA-58892
  • Manufacturer: CTC Parker Automation
  • Series: P2 PowerStations

P21-012AR Technical Specifications

Manufacturer CTC Parker Automation
Series P2 PowerStations
Part Number P21-012AR
Shipping Weight 15 lb
Display 12 inch
Memory 4 or 8MB, Fast Page Mode, 72-pin SIMM
Input Voltage 20-36 VDC, 42 Watts Max
Power Consumption 42 Watts Max
Fuse Type 3.15A, 250 VAC Littelfuse 216.315 or equivalent

About the P21-012AR

  • 4 or 8MB, Fast Page Mode, 72-pin SIMM
  • 4, 10, 20, 40MB solid state flash drive (field expandable and replaceable)

I/O Ports • 1 9-pin RS232 (non-isolated)

  • 1 9-pin RS232/422/485 (non-isolated)
  • 1 25-pin IBM parallel
  • 1 PS/2 keyboard
  • 1 RJ45 Ethernet (Novell NE-2000 compatible, onboard, 10Base-T interface

PC/104 Bus Extension

  • 16-bit, +/-5V, +/-12V

Dimensions (H x W x D)

  • 11.0" (280mm) x 13.8" (350mm) x 3.5" (89mm)

Weight 12.6 lbs. (5.6 Kg)

PC/104 Power Availability 1.5A@5V, 0.2A@12V; 75mA@-5V, 75mA@-12V

Reviews For P21-012AR

Internal Review
(5.0)

The P21-012AR features a 640x480 VGA monochrome LCD display with 16 shades of gray, providing clear visual feedback in industrial settings. It supports configurable memory options of 4 or 8MB (Fast Page Mode, 72-pin SIMM) and offers highly flexible solid-state flash drive storage options (4, 10, 20, or 40MB), which are notably field expandable and replaceable. CPU choices include the PCA-6135 386SX at 40MHz or the more powerful PCA-6145L 5x86 at 133MHz, allowing for performance scaling based on application needs. Powering the unit is straightforward with a 20-36 VDC input, consuming a maximum of 42 Watts, and protected by a 3.15A, 250 VAC Littelfuse. Connectivity is a strong suit, with a comprehensive array of I/O ports. — AX Control Lead Technician
