ISM1412-01 Image One
3 year warranty

❯

ISM1412-01 Image 1
ISM1412-01 Image 2
ISM1412-01 Image 3
visa card logo american express logo master card logo bbb logo duns seal

ISM1412-01

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
The ISM1412-01 model requires a minimum firmware of 4.6.0 and has a 1/1.8" CMOS sensor. It was designed by Cognex Vision for the In-Sight Micro Vision Systems. This model is grey-level and does not have any color pixels.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a ISM1412-01 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1412-01
  • SKU: ISM141201CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1412-01 Technical Specifications

Dimensions with Mounting Block 30 mm (1.18 in) x 38.2 mm (1.50 in) x 60 mm (2.36 in)
Electronic Shutter Speed 16 microseconds to 950 milliseconds
Firmware In-Sight Version 4.6.0
Frame Rate 60 Full Frames Per Second
Image Processing Memory 256 MB SDRAM
Lens Type CS-Mount and C-Mount
Protection IP51 w/ Cables and Lens Attached
Serial Communication None
Status LEDs 3; 2 User-Configurable and Network

Product Description

The ISM1412-01 model is just one of the many In-Sight Micro System models. They are used for getting into small and hard-to-reach places. This model is a stand-alone, network-ready, vision system. There is no color bit depth associated with this model and is only a two hundred fifty-six grey level unit, which is also known as eight bits per pixel, this model is the same as the other models as long as there is no C revision at the end of the part number. The maximum pixels associated with the ISM1412-01 model is 1280 x 1024.

As previously mentioned this model is in the micro-series and is noted as such by the dimensions. There are two dimension types which are either with or without the mounting block. The model's dimensions without the mounting block are a length of one point eighteen inches by a width of one point eighteen inches by a height of two point thirty-six inches.

There are several compliance standards associated with the ISM1412-01 vision system which are CE, FCC, TÜV, EU RoHS, and several others. There is also a specific model type associated with the compliance standards and this unit which is type 821-0078-1R.

One precaution that must be taken when installing this unit is to ensure that it is not exposed to any extreme hazardous environments, which can include but are not limited to excessive dust, impact, humidity, moisture, and several others. All of the potential hazards associated with Cognex models can be located in the In-Sight Micro Series Vision System Installation Manual found in the manuals tab of this page.

Frequently Asked Questions about ISM1412-01

What is unique about the Cognex ISM1412-01 compared to other Cognex In-Sight Micro Vision Systems?
The  ISM1412-01 is of the Cognex 1412 specification. The Cognex 1412 vision systems and the Cognex 1402 vision systems are the only two specifications that accept the In-Sight version 4.6.0 as the minimum firmware requirement. The 1412 Cognex is very similar to the 1500, in that it has a 1/1.8-inch CMOS sensor type. The properties of this sensory type are a 8.7 mm diagonal and 5.3 x 5.3 micrometer square pixel specification. The 1412 Cognex vision system is unique to the 1500 in that the maximum pixel resolution is 1280 x 1024 compared to either the 640 x 480 or the 800 x 600 options of the Cognex 1500.
What is the electronic shutter speed of the Cognex ISM1412-01 In-Sight Micro Stand-Alone, Compact Vision System?
The electronic shutter speed for the ISM1412-01 In-Sight Micro Stand-Alone vision system used for identification, measurement, and robot management on the factor floor has an electronic shutter speed of 16 microseconds to 950 ms.
Is the ISM1412-01 a color vision system?
The Cognex ISM1412-01 is not a color vision system. The color systems are indicated by a C following the order specification. For example, the 1400C is a color Cognex system.

Reviews For ISM1412-01

Internal Review
(5.0)

The ISM1412-01 is the best model to use if an enhanced resolution is required as well as a higher frame rate. The resolution for this model is 1280 x 1024. - AX Control Tech Team
