ISM1400-10

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Compact, Network-Ready, Stand Alone, and more the ISM1400-10 model can be used for several automatic functions such as inspection, measurement, and even more. Due to the extended toolset on this model, it has the potential to be enhanced with a PatMax feature.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Warranty: Learn More
Sell Surplus: Have a ISM1400-10 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1400-10
  • SKU: ISM140010CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1400-10

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Compact, Network-Ready, Stand Alone, and more the ISM1400-10 model can be used for several automatic functions such as inspection, measurement, and even more. Due to the extended toolset on this model, it has the potential to be enhanced with a PatMax feature.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Warranty: Learn More
Sell Surplus: Have a ISM1400-10 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1400-10
  • SKU: ISM140010CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1400-10 Technical Specifications

Finish Painted
Model Type Vision System
Mounting Method Four M3 Threaded Mounting Holes
PatMax Enhanced Yes, according to Cognex In-Sight Micro Vision System Data Sheet
Sensor Properties 5.92 mm diagonal, 7.4 x 7.4 ┬Ám sq. pixels
Serial Communication None
Series In-Sight Micro Vision System
Status LEDs Network, 2 User-Configurable
Weight w/ Mounting Block 5.15 oz

Product Description

The In-Sight Micro Vision System ISM1400-10 was produced to operate in settings where a network-ready, stand-alone, and compact unit is required. The In-Sight Vision Systems were first introduced to the market in 2010 since then the models have only progressed in their function. One main feature associated with this unit is that it is not only compact as previously mentioned but self-contained as well which means that no other cameras or external processors are required when the system is being operated.

The ISM1400-10 model is made up of extremely rugged industrial-grade housing, some models produced by Cognex are made up of stainless steel but the ISM1400-10 model is not one of those nor is it offered in stainless steel, but the die-cast aluminum this model is made up of still makes this specific unit incredibly durable.

While this unit is not one of the models equipped with a color tool it does feature the PatMax feature which is an extension of the extended toolset. The two main features associated with the extended toolset on the ISM1400-10 model are the caliper tool and the non-linear calibration. The non-linear calibration associated with this vision system is extremely precise pick-and-place for off-axis and standard mounting due to the constraints of robot motion or space. It can also be used in applications where highly accurate measurements and dimensions are required pertaining to medical devices.

All of the above information regarding this unit can be found in Cognex publications, the main publication used regarding this unit is the In-Sight Vision System 2010 Product Guide. Another key publication associated with this model is the Cognex In-Sight Micro Series Vision System Installation Manual. It is best and highly recommended to use manuals that were most recently published to ensure all information regarding the installation is accurate and highly reliable.

Frequently Asked Questions about ISM1400-10

How would one clean the ISM1400-10 Cognex Vision System In-Sight Micro 1400 Series or other vision systems within the Cognex family?
In order to clean the exterior housing of the vision system, a mild detergent or isopropyl alcohol with a gentle cloth application may be used. Pouring the cleaning agent directly on the vision system is not recommended as cleaner can make its way to the interior of the unit and interfere with the vision system features. Harsh or corrosive elements should not be used on the housing. These solvents include lye, methyl ethyl ketone (MEK) or gasoline. An air duster is the best tool to use to remove dust or other particles from the image sensory window (exterior portion).
How does the I/O cable connect to the ISM1400-10 Cognex Vision System?
The I/O module cable connects to the ISM1400-10 in the I/O module with the DB15 connector. This I/O connection location is located at the top left aspect of the vision system when viewing the Cognex ISM1400-10 from the rear view. This cable allows for access to the high-speed outputs and to the vision systems trigger. The signal names for the I/O Module cable pin-out are HS OUT 0, Trigger +, Trigger-, HS common, and HS OUT 1.
Reviews For ISM1400-10
Internal Review

While this mother is not equipped with a color tool set it is equipped with both PatMax and an extended toolset which makes this model better than previous units. This model is one of the enhanced ISM1400 models. - AX Control Technician

Repair Services For ISM1400-10

Type Lead Time Price Action
Repair Service 1-2 weeks Ask Get Quote

Our highly skilled technicians can repair your ISM1400-10. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
