Cognex Vision System ISM1100-01 has an ID, Essential, Extended, and potential PatMax toolsets. This unit has a frame rate of sixty frames per second. The ISM1100-01 model is an enhanced model of the ISM1100-00 model.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a ISM1100-01 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: ISM1100-01
  • SKU: ISM110001CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight Micro Series Vision System

ISM1100-01 Technical Specifications

Acquistion Rate 60 Full Frames Per Second
Program/Job Memory Non-Volatile Flash Memory, 128 MB
Regulatory Compliance RoHS, CE, KCC, FCC, and TÜV SÜD NRTL
Serial Communication None, according to In-Sight Micro Series Vision System Installation Manual
Series Cognex In-Sight Micro Vision System
Shutter Speed 16 µs to 1000 ms
Supported Tools ID, Essential, Extended, and Probable PatMax
Weight w/o Mounting Block Approx. 121 Grams

Product Description

Model number ISM1100-01 is one of the many In-Sight Micro Series Vision Systems that was designed to be used in on-floor factory settings. When being used in on-floor factory settings the model can be used to assemble a factory-wide network of the Cognex Vision Systems. Not only can this model be used in a network of vision systems but it can also be used for inspection tasks that are typically single-point.

One feature that makes this vision system an excellent purchase is that it is very compact. The dimensions of the ISM1100-01 model are all under three inches, whether equipped with or without the mounting block, in width, height, or depth. Because of the small dimensions associated with this model, it is best used in applications that are typically hard to reach.

On the back of the ISM1100-01 model, there are three connectors, these connectors are underneath the I/O connector close to the left edge of the system. The three LEDs are labeled LED1, LED2, and ENET. LED1 will be green to indicate that it is active and using the Discrete Output Line 4 which is user-configurable. If using a CIO-MICRO or CIO-MICRO I/O module then the output line will be line ten.

The PoE Connector which is also on the back of the ISM1100-01 model, will provide the Ethernet connection for network communications and also supply the power to the device. Please note that the I/O module being used for the power supply should not be active while connecting any of the wirings. Connecting the wires while power is active can result in a potential shock or even in severe cases death.

Frequently Asked Questions about ISM1100-01

What are the humidity and protection characteristics of a ISM1100-01 Cognex Vision System ISM 1100 In-Sight Micro Series?
ISM1100-01 vision series has a humidity capacity of 90% non-condensing humidity. This specification applies to both storage and operating conditions for the Cognex In-Sight Micro Vision Series models. The ISM1100-01 has a protection specification of IP51 with the lens and the cable attached to the vision series.
How should the high-speed outputs be connected for the ISM1100-01 Cognex Vision System ISM 1100 In-Sight Micro Series?
The Cognex Vision System ISM 1100 In-Sight Micro Series features two high-speed outputs that are built in to the vision series. These outputs can either be a current sourcing or a current sinking line (PNP or NPN). The maximum voltage of the high speed outputs is 28VDC (external load). These outputs have a 100 mA max current (sink). The resistance to the external load is 240 Ohms to 10 kOhms. If the current inductive loads are too high the series may require an external diode for protection. If the load is lower then each line (rated at a max of 100 mA) will be protected against short circuits or over-current conditions that may be caused by switching inductive loads.

Reviews For ISM1100-01

Internal Review
(4.0)

While this model has an extended toolset and other features information is limited. All of the information available on this page was taken from two Cognex manuals, one of which is the Product Guide from 2010. - AX Control Technician
