IS8402C-363-50

About the IS8402C-363-50

• The IS8402C-363-50 is part of the Cognex In-Sight Micro 8000 line.
• It boasts a performance 15 times faster than the In-Sight Micro 1020 model.

Imaging and Data Capture Capabilities

• Captures full-color moving images at 1600 x 1200 pixel resolution with a rapid acquisition rate of 53 frames per second (fps).
• Utilizes a 1/1.8 inch CMOS sensor with a global shutter for data capture.
• Features Gigabit Ethernet for its single input trigger and two outputs for high-quality, fast data transfer.
• Includes 1-D and 2-D barcode readers, as well as OCR/OCV (Optical Character Recognition/Verification) abilities.
• Monitors and filters images, performs geometric program and pattern recognition, analyzes histogram data, handles formatting and string parsing, and offers built-in caliper assessment for non-linear product calibration.

Software and Features

• Comes installed with PatMax (Cognex's patented flaw detection technology).
• Supports Spreadsheet, JavaScript, and EasyBuilder for programming.
• Includes InspectEdge for inspecting blobs, curves, edges, and lines on assembly line products.

Physical Specifications and Requirements

• Standard Cognex product design includes a die-cast zinc frame with a yellow and black finish.
• Requires a C mount at the base, utilizing four M3 threaded mounting holes.
• M6 mounting holes are available on an optional accessory mounting block.
• The In-Sight 8402 model, along with 8200, 8400, and 8401, requires 5.2.0 firmware.
• Standard product dimensions (without accessory mounting block):
  • 31mm H x 31.2mm W x 75.1mm D (1.22 in H x 1.23 in W x 2.96 in D)
  • Weight: 132.2 grams (4.66 ounces)
• Dimensions with accessory mounting block:
  • 39 mm H x 31.2 mm W x 75.1 mm D (1.54 in H x 1.23 in W x 2.96 in D)
  • Weight: 163.2 grams (5.76 ounces)
