Product Description
IS7432-01 is a Cognex camera that is part of the InSight Vision System. This camera has 512 MB non-volatile flash memory and unlimited storage via a remote network device. The image processing memory is 256 MB SDRAM. The sensor ia a 1/1.8-inch CMOS sensor with a 8.7 mm diameter. The sensor is 5.3 x 5.3 µm sq. pixels. The camera resolution is 1280 x 1024 pixels. The electronic shutter speed is 16µs to 950ms. The acquisition is rapid reset, progressive scan, and full-frame integration. The bit depth is 256 grey levels at 8 bits/pixel. The camera operates at 60 full frames per second. The lens type is an M12 or C-mount.
There is an In-Sight 7000 series plug-in that gives the camera autofocus functionality. Gigabyte ethernet is not supported on this unit. Do not attempt to attach an M12 lens that is not from this series to your In-Sight 7000, as it may damage the camera’s functionality.
The gain settings on this unit are different from previous Cognex series, but the gain range is still the same. The user may alter the gain settings to match that of a previous series configuration. There are 4 outputs and 4 inputs on the In-Sight 7000, but one of the inputs is designated as the trigger input for the camera. CIP-Sync is not supported on this system, but all other Cognex Connect protocols are supported. Please contact AX Control for more information on this specific part and/or series.
