Product Description

The image bit depth of the In-Sight ISS-5410-000 Vision System is 256 grey levels (8 bits/pixel) at 60 full frames per second.

The following outlines the steps to install the device in your site.

1. Unbox the device and remove all the items.

2. Check the lens area and see if a protective device covers the threads. This is to protect the threads from damage.

3. Remove the protective device from the threads and screw the lens into place. Do not over tighten the lens and be careful to not scratch or smudge the lens. It might be best to wear gloves.

4. Connect all the cables. This might include a serial cable and the breakout cable. A connector is available on the device only for the breakout cable.

5. Turn on the device and load the configuration tool. Log on and configure the device.

Up to 128MB of flash memory can be installed on the device. More memory might be needed and it is available through the network.  If you have storage devices accessible on the network your can add more  memory for your requirements. As your needs change, you can remove memory and use it for other purposes in the site.

Many factors are part of the process to design and equip the installation site for the device. Allow for the following requirements for the installation of the  In-Sight ISS-5410-000 Vision System.

• The device comes with screws for installation. Make sure the screws can secure the device or you have another method of installation.

• Make sure a reliable and secure source of 24VDC (plus or minus) 10%, 500mA maximum is nearby.
