The IS5610 model is one of the In-Sight Vision Systems produced by Cognex. This model is a compact and network-ready device and will be used in a variety of applications directly on the factory floor; some applications are robot guidance and measuring.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a IS5610 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS5610
  • SKU: IS5610CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight 5000

IS5610 Technical Specifications

Part Number IS5610
Series In-Sight 5000
Manufacturer Cognex Vision
Dimensions 3.93" x 4.89" x 2.42" with Lens Cover Installed
Weight 14.4 oz
Sensor Type 1/3" CCD
Resolution 640 x 480 pixels

About the IS5610

The Cognex IS5610 is a fixed-mount identification (ID) reader from Cognex. A member of the In-Sight 5000 series, this device offers high-speed code reading capabilities. IDMax software allows the camera to read and verify text and 1- and 2- dimensional barcodes. Advanced OCR/OCV tools make text reading and verification possible on this device. The system can read codes at over 7200 ppm, highlighting the device’s integrated speed. A 20 times speed rating and an image acquisition rate of 60 frames per second ensure that all captured images are shot in real-time.

All captured images are processed with 256 MB of photo memory. An additional 128 MB of flash storage space is available for the IS5610 to save programs and jobs. This device is a high-performance system, allowing for fast access to the tool library. A 1 GHz processor allows the device to operate these tools with ease. Some ID tools available on this device are 1- and 2-D barcode reading, text reading, and image filters. To run the system In-Sight firmware version 4.4.3 (or later) must be installed for proper functionality. Additional network capabilities are available via the built-in Ethernet or 10/100/1000 BaseT protocol. External I/O modules can interface with this device using a serial RS232C connection.

Following provided installation and storage protocols will ensure that IS5610 operates within its limits. When installed on a production line, ambient temperatures should be monitored to maintain a safe operating range. These can range from 32° to 113°F (0° to 45°C) with non-circulating air. Storage temperatures can be as low as -22°F (-30°C) to as high as 176°F (80°C). An installation and safety guide is provided in the user manual and any available device datasheets.

Frequently Asked Questions about IS5610

What is the IS5610 model?

The IS5610 model is one of many In-Sight vision systems produced by Cognex. This model is essentially a camera that can be used for identification, measuring, robot guidance, and automated inspection on the factory floor. This model is best when requiring a model that can be configured easily and efficiently.

What are the components of the IS5610 model?

There are three primary components of the IS5610 model, the 50 mm lens cover kit, the mounting screw kit, and the thread guard. The thread guard and lens cover kit are vital to use when the model is not in use as it helps protect the model from the environment so dust and dirt do not inhibit the model when using it in the future.

Reviews For IS5610

Internal Review
(4.0)

While the IS5610 model is an excellent and compact model that can be used wherever you need to use it, the downside to this model is that the sensor is not as large as some of the other In-Sight 5000 models, which could affect how it can be used in factory settings. - AX Control Tech

Repair Services For IS5610

Type Lead Time Price Action
Repair Service 1-2 weeks $1999

Our highly skilled technicians can repair your IS5610. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
