In-Sight IS5403-00 Vision System

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a IS5403-00 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

IS5403-00

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
In-Sight IS5403-00 Vision System

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a IS5403-00 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

IS5403-00 Technical Specifications

Manufacturer Cognex
Part Number IS5403-00
Series In-Sight 5000 Series

Product Description

The In-Sight IS5403-00 Vision System contains one 10/100 BaseT Ethernet port with an RJ-45 connector and one RS-232C port for serial communications. The breakout cable provides the connection for the RS-232C and the power, trigger, and high-speed outputs.

The In-Sight IS5403-00 Vision System features Power, Network Status, and Network Traffic indicator LEDs. The LEDs are configured by the organization for purposes they require

The IS5403-00 contains 128MB of memory. The type of memory the device contains is non-volatile flash.  You can connect the device to a remote storage device for unlimited storage.  The memory dedicated to image processing is 256 MB. The resolution is 1600x1200. The sensor type is 1/1.8-inch CCD. The weight is 350 g (12.3 oz.) with a lens cover but no lense installed. e lens cover installed and without the lens. The IS5403-00 features a die-cast aluminum housing.

The image bit depth of the In-Sight IS5403-00 Vision System is 256 grey levels (8 bits/pixel) at 14 full frames per second.

In the range between 0°C and 45°C (32°F to 113°F) is the recommended temperature. The operating  humidity is 95%, non-condensing (operating and storage). The Ingress Protection rating is IP67 (with appropriate lens cover installed). The vibration rating (shipping and storage) is 10 G from 10-510 Hz with 150 gram lens per IEC 68-2-6. The shock rating (shipping and storage) is 80 G shock with 150 gram lens attached per IEC 68-2-27.

In-Sight firmware version 4.4.3 is the earliest firmware recommended for the IS5403-00.

Make sure you can have an electrical connection for the device that supplies 24VDC ±10% power at 500mA or less. This is the external power requirement.





Frequently Asked Questions about IS5403-00

What revisions can I request?
Please feel free to ask the AX Control sales representative for the precise revision you need and they will do their best to accomodate your request. Rev. C is a common revision for this particular camera.
