IS5400-CS11

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.71 (7)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.71 (7)
  • Click a star to rate this product
Model IS5400-CS11 is a Cognex Stainless Steel Vision Color Sensor with (optional) PatMax and PatFind for twice the amount of overall performance vs. a 5100 model.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a IS5400-CS11 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS5400-CS11
  • SKU: IS5400CS11CV
  • Manufacturer: Cognex Vision
  • Series: In-Sight 5000

IS5400-CS11 Technical Specifications

Manufacturer Cognex
Series In-Sight 5000 Series Vision System
Operating Temperature 0°C to 45°C (32°F to 113°F)
Dimensions 43.5mm (1.71in) x 123.2mm (4.85in) x 61.4mm (2.42in) without Lens Cover installed
Environment Protection IP67
Regulation Compliance CE, UL, CUL, FCC, RoHS
Pixel Resolution 640 x 480
Sensor Type 1/3-inch CCD
Sensor Properties 5.92mm diagonal, 7.4 x 7.4μm sq. pixels
Picture Acquisition 24 bit color at 60 frames/second

About the IS5400-CS11

The Cognex Insight 5000 part number IS5400-CS11 is a powerful and versatile machine vision system designed for industrial applications. It offers advanced image processing capabilities and high-performance inspection tools to ensure accurate and efficient quality control.

Key Features of the Cognex Insight 5000 IS5400-CS11:

  1. Image Acquisition: The IS5400-CS11 utilizes high-resolution image sensors to capture detailed images of the inspected objects. It supports various types of cameras, including GigE Vision and Camera Link, enabling flexible integration into existing setups.

  2. Processing Power: Equipped with a robust processing engine, the Insight 5000 IS5400-CS11 delivers fast and reliable image analysis. It can handle complex inspection tasks and perform real-time image processing with low latency.

  3. Vision Tools: The Cognex Insight 5000 comes with a wide range of pre-configured vision tools that facilitate rapid application development. These tools include pattern matching, measurement gauges, barcode reading, OCR (Optical Character Recognition), and defect detection algorithms.

  4. Communication and Connectivity: The IS5400-CS11 supports various communication protocols, such as Ethernet/IP and PROFINET, allowing seamless integration into industrial automation systems. It also provides I/O options for interacting with external devices and equipment.

  5. Programming and Configuration: The Insight 5000 IS5400-CS11 employs Cognex's powerful and user-friendly VisionPro software for application development and configuration. VisionPro offers a comprehensive set of tools for creating inspection programs, setting up communication interfaces, and fine-tuning the system for optimal performance.

  6. Optional PatMax Option: When combine with the PatMax and Pat Find Software, the 5400CS Model provides enhanced capabilities for pattern recognition and part localization. It enables the sensor to accurately and efficiently detect and analyze objects based on their unique patterns, significantly improving overall performance. With PatMax, the IS5400-CS11 can handle more complex inspection tasks and achieve higher throughput, contributing to increased productivity and quality assurance in industrial settings.

Frequently Asked Questions about IS5400-CS11

What is the IS5400CS Model and the PatMax software?

The Cognex Vision Model 5400CS is a Stainless Steel unit with Color Sensing and (optional) PatMax and PatFind for a combined double overall performance vs. a standard 5100 model. PatMax is a powerful and widely-used pattern matching algorithm developed by Cognex. It excels at identifying and locating complex patterns, even in challenging conditions with variations in lighting, scale, rotation, and perspective. By leveraging advanced geometric algorithms, PatMax can achieve high levels of accuracy and reliability in industrial inspection and quality control applications. Furthermore, the IS5400-CS11's stainless steel construction ensures its durability and suitability for harsh operating environments, making it ideal for industries such as food and beverage, pharmaceuticals, and automotive manufacturing.

Reviews For IS5400-CS11

Internal Review
(5.0)

The IS5400CS model is a very durable piece of equipment for its size and application. We rarely get repair or replacement requests for this unit likely due to its limited plastic components and hefty stainless steel body. - AX Control Tech

Repair Services For IS5400-CS11

Type Lead Time Price Action
Repair Service 1-2 weeks $1875

Our highly skilled technicians can repair your IS5400-CS11. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
