The Cognex IS5403-11 Machine Vision System with PatMax offers Highest resolution (1600 x 1200) imaging from a larger CCD Sensor



Sell Surplus: Have a 825-0221-1R to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 825-0221-1R
  • SKU: 82502211RCV
  • Manufacturer: Cognex Vision
  • Series: In-Sight 5000

825-0221-1R Technical Specifications

Housing Material Painted Die-Cast Aluminum
Power Requirement 24VDC ±10%, 500mA maximum
Storage Temperature –30°C to 80°C (22°F to 176°F) @ 95% Humidity
Minimum Firmware In-Sight version 2.80.01 PR1
Resolution (Pixels) 1600 x 1200
Sensor Size 1/1.8-inch CCD (8.8mm diagonal, 4.4 x 4.4μm sq. pixels)
Frames Acquisition 14 full frames per second
Color Acquisition 256 grey levels (8 bits/pixel)
Electronic Shutter Speed 27μs to 1000ms
Model Type IS5403

Product Description

The 825-0221-1R is a specific component of the Cognex Insight 5000 series, a comprehensive line of industrial scanners, cameras, and vision sensors developed and manufactured by Cognex Visions. These devices are designed for diverse industrial applications and feature a standardized design with a distinctive bright yellow color accented with black. This uniform appearance ensures easy recognition and identification of Cognex equipment.

Physically, the In-Sight 5000 models, have compact dimensions of 1.71 in. x 4.89 in. x 2.42 in. without the lens cover. With the lens cover, the dimensions slightly increase to 3.28 in. x 4.89 in. x2.42 in. The weight of the unit is approximately 12 ounces.

The In-Sight 5000 models have a CCD module for efficient barcode processing and inventory management. The CCD size and image resolution may vary across specific models within the series. Additionally, factors such as FPS rating and bit depth also differ. However, all models in the In-Sight 5000 series share standard acquisition features, including rapid reset, full-frame integration, and progressive scanning capabilities.

What truly sets the 825-0221-1R apart is the inclusion of the powerful PatMax software. PatMax employs advanced geometric algorithms, enabling it to excel in complex pattern-matching tasks. Regardless of challenging conditions such as variations in lighting, scale, rotation, or perspective, PatMax reliably identifies and locates intricate patterns. This capability is critical for achieving precise object detection and localization, enhancing quality control and inspection processes.

Complementing the PatMax software, the 825-0221-1R is equipped with a comprehensive suite of vision tools provided by the Cognex Insight software. These tools encompass measurement gauges, barcode reading, OCR (Optical Character Recognition), defect detection algorithms, and more. This diverse range of tools enables the system to address various inspection requirements and perform precise measurements, further enhancing its versatility and utility.

With its robust processing engine, the 825-0221-1R performs fast and accurate image analysis. It handles complex inspection tasks effortlessly and ensures real-time image processing with low latency. This capability is pivotal for maintaining efficient production line operations.
