With a monochrome CMOS imager to earn the “M” in its designation, the Cognex In-Sight IS2000M-110-30-125 visual sensor is one in a series of industrial monitoring equipment has a lightning fast shutter with an operating speed of 0 to 1000 milliseconds. The IS2000M-110-30-125 is powered by 24 DC volts and 48 watts of energy for the integrated lights; a series of red, blue, and infrared LED ring lights, lens filters, and polarized light cover. With a lighting system this thorough, no additional external lights are necessary for the sensor to function.
Operating with 32 megabytes for function and 128 MB of SDRAM for image processing, this model records and analyzing with its complementary metal-oxide semiconductor (CMOS) imager (4.8 millimeter width and 3.6 millimeter height) able to capture 3.75 micrometers of pixels, using the 8 mm lens and S Mount. The standard image mode has a 640 x 480 resolution, and a bit depth of 256 grey levels at 8 bits per pixel.
To be user-friendly for the industrial assembly line workforce, the IS2000C-110-30-125 is programmed with an easy to use user interface, the In-Sight Explorer EasyBuilder, the Cognex VisionView PC Software, and the VisionView 900 human machine interface touchscreen panel.
6 IO ports are built in, and the IP-65-graded aluminum alloy frame is yellow and black, and this model’s dimensions match the In-Sight standard hardware specs of a length of 92 mm, a width of 60 mm, a height of 52 mm, and weighing 200 grams.
