F4-04DAS-1 Isolated Analog Output Module

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a F4-04DAS-1 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

F4-04DAS-1

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.70 (6)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.70 (6)
  • Click a star to rate this product
F4-04DAS-1 Isolated Analog Output Module

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a F4-04DAS-1 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

When using the F4-04DAS-1 Isolated Analog Output Module with the H4-EBC Ethernet Base Controller, make sure the H4-EBC contains firmware version 2.1.46 or later.

The F4-04DAS-1 is a 4-channel analog output module. The output range is 4-20 mA. The number of channels is 4, isolated current sourcing. The resolution is 16 bit (1 in 65536). The power budget requirement is 60mA @ 5VDC (supplied by base). The environmental air requirement is no corrosive gases permitted. The operating temperature 0–60°C (32–140°F). The relative humidity 5–95% (non-condensing).

The PLC update rate is 1 channel per scan minimum, 4 per scan maximum. The output points required is 32 (Y) output points 16 binary data, 2 channel identification, 1 bit output enable). The F4-04DAS-1 Analog Output Voltage Module contains valuable hardware features.

  • The analog outputs are isolated from other outputs

  • For improved usability and portability, the terminal block is easily removable to ensure the F4-04DAS-1 Analog Output Voltage Module is easily removable without disconnecting wiring.

  • If a DL440 or a DL450 CPU is used, all four analog outputs may be set in one CPU scan.

  • If used with independent loop power supplies, the module provides four channels of isolated current outputs.

When wiring the F4-04DAS-1 Isolated Analog Output Module, consider the following information.

  • Use the shortest wiring route.

  • Be sure to use shielded wiring and ground the shield at the transmitter source.

  • To avoid electrical noise, keep away from large motors, high current switches and transformers when planning the wiring route.

  • To avoid damage, route the wires through approved cable housing only. Follow all applicable codes to select the correct housing.






Repair Services For F4-04DAS-1

Type Lead Time Price Action
Repair Service 1-2 weeks $166

Our highly skilled technicians can repair your F4-04DAS-1. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
