D4-08TA 18-220VAC Output Module

D4-08TA

  • {{ avg.toFixed(1) + ' (' + ratingCount + ')' }}
  • {{ message }}
D4-08TA 18-220VAC Output Module

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a D4-08TA to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The D4-08TA 18-220VAC Output Module is a 8-point 18-220VAC output module.

The inrush current is 30A for 10 ms and 10A for 100 ms at the highest rating. The module contains 2 commons. The commons are isolated. The specification for the operating voltage is between 15 and 265VAC. The output type is SSR (triac).

The module boasts a peak voltage power of 265 VAC.

The AC frequency is 47-63 Hz. The maximum leakage current is 5mA at  265VAC. The required 5V base power is 250 mA max. You cannot replace the fuses. There are two fuses in the module. The fuses are rated as 8A. The weight is 11.6 oz. (330g). The terminal block can be removed.

The operating temperature is 32° F to 140° F (0° C to 60° C). The operating humidity is  5% to 95% relative humidity (non-condensing).

Each point on the module has a logic side indicator. The on or off status of the indicator reflects the status of the point with respect to the CPU. Consider that the status indicators could be operating normally while the actual output device could be damaged.

The logic side indicators have an on and off status. They show the status of the point as it relates to the CPU. It is useful for troubleshooting.
