A logic-side indicator is provided for each point on the D4-08ND3S 24-48 DC Input Module. They indicate the state of the point as it relates to the CPU. It is useful for diagnostics and troubleshooting.
Another useful troubleshooting step is to replace a failed module. If the problem is not resolved it might be another device has stopped working.
Specifications for the D4-08ND3S 24-48 DC Input Module.
Points: 8 (sink or source).
The D4-08ND3S is a 24-48 VDC discrete input module.
The input voltage is from 20 to 52.8VDC.
Input current: 5 mA when running at 24VDC and 10 mA when running at 48VDC.
8 isolated commons and each common is associated with 1 point per common.
Peak voltage: 52.8VDC.
Terminal block (D4-16ICON) can be removed.
The base power: 5V is 100 mA at the highest rating.
No supply auxiliary at 24 VDC.
The weight is 8.8oz. (250g).
From 32° F to 140° F (0° C to 60° C) is the air temperature during operation. The operating humidity is 5% to 95% relative humidity (non-condensing).
