Home Automation Direct DirectLogic 205 T1K-01AC

❮

❯

About | Product Specifications | FAQs

T1K-01AC

4.33 (3)
Click a star to rate this product

4.33 (3)
Click a star to rate this product

The T1K-01AC model is part of the DirectLogic205 series produced by Automation Direct. This model is used with AC inputs. The input voltage range for this model is 110/220 VAC.

Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a T1K-01AC to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: T1K-01AC
SKU: AD-54037

Manufacturer: Automation Direct
Series: DirectLogic 205

Description
Repairs
Warranty
Manuals

T1K-01AC Technical Specifications

Part Number	T1K-01AC
Series	DirectLogic 205
Manufacturer	Automation Direct
Module Type	Power Supply I/O
Fuse	1 Primary
Ripple at 24 VDC	Maximum 10%
Maximum Inrush Current	20A
Input Frequency	50/60 Hz

About the T1K-01AC

The T1K-01AC module is one of the Terminator I/O modules and is offered with an AC power supply option. This model is labeled as one of the power supply units within the DirectLogic 205 series produced by Automation Direct. This model will operate on an input voltage range of 110/220 VAC or 85-264 VAC; this model is slightly more enhanced than the T1K-01DC module as it is equipped with an input frequency. The input frequency on this model is 50/60 Hz. Another difference between the two different power supplies is that this model has an auxiliary 24 VDC supply while the T1K-01DC unit does not since its input voltage range is 12/24 VDC.

When the T1K-01AC model is being installed, it will be DIN-rail mounted and installed with other models in the Terminator I/O system. This unit has the capability to be mounted vertically or horizontally, but to ensure proper airflow occurs to keep the model cool at all times, the unit must never be installed upside down. For more information regarding the installation procedures of the T1K-01AC unit, refer to the Automation Direct T1K-INST-M Installation Manual attached above, as well as all associated documentation and data sheets.

Frequently Asked Questions about T1K-01AC

What is the T1K-01AC module?

The T1K-01AC module is a termination power supply module. It is mounted with termination modules within the DirectLogic 205 series as an external or auxiliary user supply.

What is the power budget of the T1K-01AC?

There are two different power budgets for the T1K-01AC module depending on which voltage it is used; if the module is used in 5VDC, the power budget is +2000mA, and when the module is in 24 VDC, the power budget is +300mA.

Reviews For T1K-01AC

Internal Review

(5.0)

The T1K-01AC model is the sister module of the T1K-01DC module. This module is better compared to the T1K-01DC module since the T1K-01AC module has two outputs while the T1K-01DC unit does not. The T1K-01AC module is an excellent purchase when requiring an auxiliary or external user power supply. - AX Control Tech

Repair Services For T1K-01AC

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$279

Our highly skilled technicians can repair your T1K-01AC. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

48-72hr Rush Repair
Detailed Repair Reports
AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.

All PLCs, HMIs, and Turbine Control Boards:	3 Years
All AC/DC and Servo Drives:	2 Years
All Motors:	1 Year
