Status indicators are available on the H2-WPLC2 WinPLC Module.
POWER and RUN The control software you are using determines what these indicators mean..
LINK When lit, the connection is working.
ACT Network data is be received or sent. .
ERROR An error has occurred.
The H2-WPLC2 WinPLC Module supports the 10BaseT Ethernet standard. A standard RJ45 modular connector is contained in the device. The RJ12 RS232C serial port is a feature of the H2-WPLC2. The CPU slot on the DL205 base can receive the device.
Use the Workbench tool is used to, load new ROM images on the WinPLC and set up the IP address. The Workbench also can be used for troubleshooting and checking the operation of the device.
he Workbench can also be used to configure TCP/IP communications, and discrete and analog input and output modules.
