The H2-WPLC1 WinPLC Module uses the 10BaseT Ethernet standard. The RJ45 connector is used to connect the H2-WPLC1 WinPLC Module to the network. The serial port connects to many devices that support serial connection.
The H2-WPLC1 WinPLC Module can be inserted in a CPU slot on the DL205 base. The input and output modules communicate through the backplane with the module.
Status indicators are available.
POWER and RUN The control software in use controls these two indicators.
LINK Network activity is in progress.
ACT Indicates network activity.
ERROR A hardware error is indicated.
The workbench tools configures the H2-WPLC1 and to define the IP address. Also, use Workbench to troubleshoot and check that the WinPLC and all I/O devices are functioning properly.
You run the Workbench from a laptop. Make sure the laptop has TCP/IP and IPX/SPC installed. Input modules, output module, analog input module, analog output modules, and TCP/IP Communications, can be defined using Workbench.
