F2-04AD-2, 4-Channel Analog Voltage Input Module

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a F2-04AD-2 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

F2-04AD-2

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (6)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (6)
  • Click a star to rate this product
F2-04AD-2, 4-Channel Analog Voltage Input Module

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a F2-04AD-2 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The F2-04AD-1, 4-Channel Analog Voltage Input Module contains some features to improve reliability, usability, and flexibility.

  • The analog inputs are optically isolated from the PLC logic.

  • For improved usability and portability, the terminal block is easily removable to ensure the F2-04AD-1, 4-Channel Analog Voltage Input Module is easily removable without disconnecting wiring.

  • If a DL250-1 or a DL260 CPU is used all four channels can be updated in one scan.

  • The F2-04AD-1 contains an on-board active analog filtering and a microcontroller with RISC-like characteristics.

  • The F2-04AD-1 contains on-board 250 ohm ½ watt precision resistors.

The F2-04AD-1, 4-Channel Analog Voltage Input Module is a 4-channel analog input voltage module. The input range is 0-5 VDC and 0-10 VDC. The number of channels is 4, single ended (one common). The resolution is 12 bit (1 in 4096). The power budget requirement is  100 mA (*50 mA maximum, 5 VDC (supplied by base). The environmental air requirement is no corrosive gases permitted.  The operating temperature 0-60°C (32-140°F). The relative humidity 5–95% (non-condensing).

The PLC update rate is 1 channel per scan maximum (DL230 CPU) and 4 channels per scan maximum (DL240/250-1/260 CPU). The input points requirement is 12 binary data bits, 2 channel ID bits, 2 diagnostic bits 16 point (X) input module.

The F2-04AD-1 can be installed in any slot in a DL205. Considerations are the available power budget and the discrete I/O points. The analog input module appears as a 16-point discrete input module in configuration.
