Automation Direct Facts Engineering Koyo PLC Direct D2-230 CPU Module 2.4K Words 1 RS-232 Port DL205

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a D2-230 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: D2-230
  • SKU: D2230AD
  • Manufacturer: Automation Direct
  • Series: DirectLogic 205

About the D2-230

The Automation Direct Facts Engineering Koyo D2-230 is a central processing unit (CPU) module. It is one of a number of modules created for the DirectLogic 205 series of programmable logic controllers. If size is a concern with the PLC, then this small and economical CPU is the perfect choice. A cache of 2.0K of EEPROM program memory is available in this module. Critical data storage occurs in the V-memory system, a feature of all DirectLogic products. The system capacity of the module can hold 2.4K words, with 2048 EEPROM of ladder memory.

A basic unit, this module performs simple tasks with ease. D2-230 includes a basic instruction set that is capable of calculating basic Boolean and simple integer math. Features highlighted on the front plate of the module include the device’s single communications port. This input is a RS-232 port that operates as a DirectSOFT operator interface. If more horsepower or ports are needed, consider a higher series CPU module. Four LED indicator lights, including RUN, BATT, CPU, and PWR, complete the front plate of the module.

Following proper installation and usage parameters is necessary to maintain the integrity of the module. All wiring and installation graphics can be found in the DirectLogic 205 series manual. Automation Direct and Koyo provided original technical support for all DL205 series modules and controllers. Be sure to refer to the appropriate D2-230 manuals and datasheets for a complete list of technical and installation protocols.

AX Control is ready to assist you with your D2-230 needs. Please contact our office by phone or email to receive pricing for parts or repairs.

Repair Services For D2-230

Type Lead Time Price Action
Repair Service 1-2 weeks $207

Our highly skilled technicians can repair your D2-230. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

D2-230 Manuals, White Papers, Data Sheets, and Troubleshooting
