DL205 9 Slot AC Base

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a D2-09B-1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: D2-09B-1
  • SKU: D209B1AD
  • Manufacturer: Automation Direct
  • Series: DirectLogic 205

Product Description

Automation Direct's DL205 9 Slot AC Base is a product of Koyo and PLC Direct's collaboration. This 9 slot base includes one CPU slot. Two compatible bases are the H2-DM1 and H2-DM1E Do-More CPUs that fit into the CPU slot. For safe storage, keep this base at -20 and 70 degrees Celsius. To keep the base safe in use, The device should stay at an ambient temperature that is between 0 and 55 degrees Celsius. The dimensions of the drive are 14.09 x 3.54 x 2.95 and weighs 530g. The NEMA Structure of the base has a built-in noise resistance. All the devices in the DL205 family have up to 1536 possible expandable I/O points. You can also connect this base to other devices using the base's remote I/O through the use of Ethernet. The device can also be mounted and is free to be placed anywhere.

The DL205 9 Slot AC Base can consume a maximum of 80 VA electrical power. The input voltage range is between 85 and 132 VAC. The input power type of the device is an 100-200 VAC. The inrush current should not exceed 30 amps at any given time. The DL205 9 Slot AC Base also has an auxiliary 24 VDC output that adds more power options for the system.

The module is listed as D2-09B-1 and the D2–USER–M Manual assists the user in making the machine function properly. Call us now to get pricing quotes and information about our warranties.

Repair Services For D2-09B-1

Type Lead Time Price Action
Repair Service 1-2 weeks $110

Our highly skilled technicians can repair your D2-09B-1. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
