The D2-04BDC1-1 module is a power supply base manufactured by Automation Direct to be used with the DirectLogic 205 series. During the operation of this model, the power supplied to the units installed into the base is 24 VDC.



Sell Surplus: Have a D2-04BDC1-1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: D2-04BDC1-1
  • SKU: D204BDC11AD
  • Manufacturer: Automation Direct
  • Series: DirectLogic 205

D2-04BDC1-1 Technical Specifications

Part Number D2-04BDC1-1
Series DirectLogic 205
Manufacturer Automation Direct
Model Type Power Supply Base
Power Supplied at 5V 2600 mA
Base Power Supply 24 VDC
Dimensions 7.99" x 10.07" x 9.48" x 10.90"
Noise Immunity NEMA; ICS3-304
Atmosphere No Corrosive Gases Permitted

Product Description

Manufactured by Automation Direct as part of the DirectLogic 205 series, the D2-04BDC1-1 module is labeled as a power supply base. When used as a base, the power supplied to the attached models is 24 VDC. The model will provide 2600 mA at 5V. This is one of the models in the DirectLogic 205 series that does not offer an additional 24 VDC auxiliary power supply with external power connections meaning that it can not connect or power external devices.

One of the excellent things about the D2-04BDC1-1 module being used in a DL205 PLC system is that the DL205 system itself is flexible and can work in a number of different wiring configurations. As a 24 VDC power supply base, the unit is best used when needing to save on cost. The model can power combined loads and, when doing so, can provide up to 300 mA. Caution should always be taken when operating this model, but caution should be taken when using the base with several attachments, as it is possible that when the model exceeds the current rating, it can cause errors and potential injury.

This model is also designed to be used in application environments where low-voltage DC power is readily available compared to that of the AC power supply. All information on how the model will be used in the DL205 PLC system can be found in the D2-USER-M manual.

Frequently Asked Questions about D2-04BDC1-1

What type of model is the D2-04BDC1-1?

The D2-04BDC1-1 model is a 24 VDC power supply base for the DirectLogic 205 family. When the model is used with other DL205 units, it will provide a power supply of 2600 mA at 5 volts. This model does not have an auxiliary power supply that can be used with additional external supply drives.

What is one of the cautions that need to be taken when using the D2-04BDC1-1?

One of the main precautions that should be taken when using the D2-04BDC1-1 is that provision should be made to avert the rated voltage from being exceeded by transient disturbances that could exceed more than 40%.

Reviews For D2-04BDC1-1

Internal Review

One of the downsides of owning the D2-04BDC1-1 model is that it cannot be used to connect external power connections, making this model a less desired model than ones such as the D2-03B-1, D2-04B-1, or D2-06B-1, which can connect external power connections. - AX Control Tech
