F0-2AD2DA-2

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures 5.00 (5) Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (5)
  • Click a star to rate this product


The F0-2AD2DA-2 is an Analog Combo Module with 2 Input and Output channels that was manufactured by Facts Engineering

New Surplus Factory Package
$595
SKU: 20DI1
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
New Surplus AX Control Package
SKU: 20DI2
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned
SKU: 20DI3
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Repair
$115
SKU: 20DI4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

  Shipping Weight: 2.0 lbs.

  Shipping Dimensions: 10" x 10" x 10"

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the F0-2AD2DA-2

The Facts Engineering F0-2AD2DA-2 is a combination analog voltage module. The device offers two channel in and two channel out connections. It actively converts incoming analog voltage signals into microprocessor digestible digital signals. It then processes outgoing signals back into analog voltage. The module is compatible with DirectLogic 05 and DirectLogic 06 programmable logic controllers. The PLC updates all input/output channels in a single scan. Designed for easy transport and use, the terminal blocks can be removed without affecting the wiring of the unit.

The F0-2AD2DA-2 offers user selectable input ranges, allowing selected ranges of 0-5VDC and 0-10VDC. An installed jumper on the module allows for this selection. As it interacts with the controller’s computer, there are specific software requirements that must be met to operate the module. When installing the unit into a DL05 series controller, DirectSOFT32 version 3.0c or later and firmware version 3.30 or later are required. If using a DL06 PLC instead, DirectSOFT32 version V4.0, build 16 or later and firmware version 1.00 or later are needed.

Longevity of the device is dependent upon following all outlined storage and installation parameters. When installed in a controller, ambient temperatures can range between 0℃ and 60℃, or 32℉ and 140℉. Storage temperatures have more flexibility, with the lowest sustained temperature reading -20℃, or -4℉, and the highest reading 70℃, or 158℉. Technical support for this module was originally serviced by Automation Direct. Be sure to refer to the device’s user manual and datasheet for all safety and technical information.

F0-2AD2DA-2 Manuals, White Papers, Data Sheets, and Troubleshooting

F0-2AD2DA-2 Technical Specifications

Part Number F0-2AD2DA-2
Manufacturer Facts Engineering
Card Type Analog Combo Module
Series DL06
Input Channels 2 Channels
Output Channels 2 Channels
Input/Output Resolution 12-bit resolutions
Voltage Signal Range 0-5 VDC or 0-10 VDC
Software DirectSOFT
External Power Requirement 24 VDC

Frequently Asked Questions about F0-2AD2DA-2

Are there different V-memory locations for the input and output data?

Yes, the input and output data are stored on different V-memory outputs. Input data is stored on 701, 711, 721, and 731. Output data can be found on 702, 712, 722, and 732.

Can the analog inputs be used in the PID loops that the DL06 CPU has?

Yes, the analog inputs can be used as process variables for the 8 PID loops that the DL06 CPU has.

Reviews For F0-2AD2DA-2

Internal Review
(5.0)

The F0-2AD2DA-2 provides a level of flexibility that allows users more freedom when using the option card. The F0-2AD2DA-2 can be installed in any open option slot on the DL06 PLC. The F0-2AD2DA-2 can also be used in the Direct Logic 05 series. This module has both input channels and output channels, as it is an analog combo module. - AX Control Lead Technician
