Home Automation Direct DirectLogic 06 F0-08ADH-2

❮

In Stock
F0-08ADH-2
3 year warranty

❯

F0-08ADH-2
FactsEngineering_F0-08ADH-2
DL06_F0-08ADH-2
F0-08ADH-2_AnalogInputModule
visa card logo american express logo master card logo bbb logo duns seal

About | Product Specifications | FAQs

International

Phone

1-919-372-8413

Domestic (US)

1-800-991-7026

Email

F0-08ADH-2

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures 4.43 (7) Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.43 (7)
  • Click a star to rate this product


The F0-08ADH-2 is an 8 Channel Analog Input Module with an external power requirement of 24 VDC that was manufactured by Facts Engineering

New Surplus Factory Package
$560
SKU: 18DI1
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
New Surplus AX Control Package
SKU: 18DI2
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned
$375
SKU: 18DI3
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
Repair
$135
SKU: 18DI4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

  Shipping Weight: 2.0 lbs.

  Shipping Dimensions: 8" x 8" x 8"

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the F0-08ADH-2

The Facts Engineering F0-08ADH-2 is an optional analog voltage input module. This unit is one of many optional modules compatible with DirectLogic 05 and DirectLogic 06 series programmable controllers. An eight channel module, this unit converts analog voltage signals into digitally compatible signals. All eight channels are updated with every scan of the processor. Designed with user interfacing in mind, removal of the terminal block does not interfere with the device’s wiring.

High quality analog conversions are possible through a number of integrated system features. Active analog filtering and an internal microcontroller process the converted signal to maintain data precision. As F0-08ADH-2 interacts with RISC-like processors, certain software requirements must be met. When installed in a DL05 controller, the module requires DirectSOFT32 version 3.0c or later and firmware version 5.20 or later. When installed in a DL06 PLC, DirectSOFT32 version 4.0, Build 16 or later and firmware version 2.30 or later are necessary.

There are some specifications to know about the F0-08ADH-2. These are:

  • All 8 channels can be scanned at the same time
  • Removable terminal block
  • Analog inputs can be used as process variables for the 8 PID loops in DL06 CPUs

F0-08ADH-2 Manuals, White Papers, Data Sheets, and Troubleshooting

F0-08ADH-2 Technical Specifications

Part Number F0-08ADH-2
Card Type Analog Input Module
Series DirectLOGIC 06
Manufacturer Facts Engineering
Number of Channels 8 Channels
Software DirectSOFT
Input Resolution 16-bit
External Power Requirement 24 VDC
Input Range 0-5 VDC or 0-10 VDC
Non Insolated Input Commons 1

Frequently Asked Questions about F0-08ADH-2

Can the F0-08ADH-2 work as a power supply for external devices?

No, the F0-08ADH-2 does not supply any power to external field devices. A separate power source from the PLC will be needed for these field devices.

What do the V-memory locations do?

The V-memory locations specify the number of channels that will be scanned, along with the type of data for the module. These locations also tell which V-memory locations store the input data.

Reviews For F0-08ADH-2

Internal Review
(5.0)

The F0-08ADH-2 is an Analog Input Module that has 8 channels. All 8 channels can be scanned at the same time by the DL06 module that it is connected to. The F0-08ADH-2 can also be used with the Direct Logic 05 series, which makes this a flexible option for users. The F0-08ADH-2 can change input signal voltage levels based on the position of the jumper. The input signal voltage levels can either be 0-5 VDC or 0-10 VDC. - AX Control Lead Technician

F0-08ADH-2 Technical Specifications

Part Number F0-08ADH-2
Card Type Analog Input Module
Series DirectLOGIC 06
Manufacturer Facts Engineering
Number of Channels 8 Channels
Software DirectSOFT
Input Resolution 16-bit
External Power Requirement 24 VDC
Input Range 0-5 VDC or 0-10 VDC
Non Insolated Input Commons 1

About the F0-08ADH-2

The Facts Engineering F0-08ADH-2 is an optional analog voltage input module. This unit is one of many optional modules compatible with DirectLogic 05 and DirectLogic 06 series programmable controllers. An eight channel module, this unit converts analog voltage signals into digitally compatible signals. All eight channels are updated with every scan of the processor. Designed with user interfacing in mind, removal of the terminal block does not interfere with the device’s wiring.

High quality analog conversions are possible through a number of integrated system features. Active analog filtering and an internal microcontroller process the converted signal to maintain data precision. As F0-08ADH-2 interacts with RISC-like processors, certain software requirements must be met. When installed in a DL05 controller, the module requires DirectSOFT32 version 3.0c or later and firmware version 5.20 or later. When installed in a DL06 PLC, DirectSOFT32 version 4.0, Build 16 or later and firmware version 2.30 or later are necessary.

There are some specifications to know about the F0-08ADH-2. These are:

  • All 8 channels can be scanned at the same time
  • Removable terminal block
  • Analog inputs can be used as process variables for the 8 PID loops in DL06 CPUs

F0-08ADH-2 Manuals, White Papers, Data Sheets, and Troubleshooting

Frequently Asked Questions about F0-08ADH-2

Can the F0-08ADH-2 work as a power supply for external devices?

No, the F0-08ADH-2 does not supply any power to external field devices. A separate power source from the PLC will be needed for these field devices.

What do the V-memory locations do?

The V-memory locations specify the number of channels that will be scanned, along with the type of data for the module. These locations also tell which V-memory locations store the input data.

Reviews For F0-08ADH-2

Internal Review
(5.0)

The F0-08ADH-2 is an Analog Input Module that has 8 channels. All 8 channels can be scanned at the same time by the DL06 module that it is connected to. The F0-08ADH-2 can also be used with the Direct Logic 05 series, which makes this a flexible option for users. The F0-08ADH-2 can change input signal voltage levels based on the position of the jumper. The input signal voltage levels can either be 0-5 VDC or 0-10 VDC. - AX Control Lead Technician
