F0-04TRS

5.00 (1)

Click a star to rate this product

5.00 (1)
Click a star to rate this product

The F0-04TRS is a 4-point relay output module with a nominal output voltage of 6-48 VDC/6-208 VAC that was manufactured by Facts Engineering

New Surplus Factory Package

SKU: 16DI1

3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

New Surplus AX Control Package

SKU: 16DI2

3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned

$354

SKU: 16DI3

3 Year Warranty:

Order Before 3PM EST

Rush Available

2 in Stock

Repair

$186

SKU: 16DI4

3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Shipping Weight: 2.0 lbs.

Shipping Dimensions: 8" x 8" x 8"

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the F0-04TRS

The F0-04TRS is a board component originally designed and marketed by Automation Direct. This component is designed to function as a 4-point relay output module.

The F0-04TRS can be used with either the DL05 or the DL06 system. The unit has a nominal output voltage of 6-48 VDC/6-208 VAC.

The F0-04TRS makes use of Automation Direct’s ZipLink wiring system, which eliminates the extremely long time it typically takes to wire PLCs to terminal block connectors. Instead, ZIPLink connectors are pre-wired to removable terminal blocks that can be moved, attached, removed, and reattached as maintenance or replacement of components occurs within your system. Relay outputs on this particular module are derated to not exceed 2 Amps per point on the terminal strip when used in conjunction with a ZipLink wiring system.

The F0-04TRS has two form-C and two form-A outputs. The unit uses four IEC.3 15 amp replaceable fuses. The unit has a maximum inrush current of 5 amps.

The F0-04TRS can be used in conjunction with either the DL05 or the DL06 CPU. With the DL05, the unit must have V. 4.70 or later firmware installed. With the DL06, the unit must have V. 1.50 or later firmware installed.

Automation Industrial maintains a number of different datasheets, manuals, and user guides associated with this product to help with successful installation, maintenance, and operation.

F0-04TRS Technical Specifications

Part Number	F0-04TRS
Manufacturer	Facts Engineering
Series	DirectLOGIC 06
Card Type	Relay Output Module
Number of Output Points	4 Points
Nominal Output Voltage	6-48 VDC
Maximum Current	3A per point
Base Power Required	250 mA max
Software	DirectSOFT
Relay Configuration	2 Form A relays; 2 Form C relays

Frequently Asked Questions about F0-04TRS

What are the two forms of relays that the F0-04TRS has?

The F0-04TRS has 2 form A relays, which are SPST normally open relays. The F0-04TRS also has 2 form C relays, which are SPDT relays.

Is the terminal block easy to remove on the F0-04TRS?

Yes, the terminal block is easy to remove from the F0-04TRS. This can be done without moving any wiring. The F0-04TRS is also easy to remove once fitted into the Direct Logic PLC.

Reviews For F0-04TRS

Internal Review

(5.0)

The F0-04TRS is a 4-point Relay Output Module that can be used in both the Direct Logic 05 and 06 series. This module can be fitted into any option slot on the PLC that users need the module for. This enables a greater amount of flexibility if users already have modules installed in an option slot. The F0-04TRS has a removable terminal block on its face. - AX Control Lead Technician
