About the EA9-T7CL
This EA9-T7CL 7" WVGA Touchpanel HMI, as revealed just above, was originally designed and manufactured with a specific insertion in the EA9 Series under the C-more line of products from Automation Direct. This EA9-T7CL 7" WVGA Touchpanel Interface is able to accept that functional role within industrial assemblies due to its adoption of various hardware parts and accessories, such as its:
- 7" Widescreen Display
- WVGA
- LED Backlight Type
- 3 Serial Ports
- 2 USB Ports
- 1 Memory Card
It should be noted that this EA9-T7CL 7" WVGA Touchpanel HMI product offering's 7" Widescreen display does necessitate the adoption of further LED backlights into its assembly; if one of these backlights should go kaput, the EA9-T7CL 7" WVGA Touchpanel HMI here is repairable today here through AX.
EA9-T7CL Power Specifications
A number of important power and environment-related specifications have been exposed for this EA9-T7CL, specifications that are critical to consider before any installation. A primary and rather obvious specification is that this EA9-T7CL HMI is unable to run concurrently to corrosive gas conditions. Some other important power/environment specs introduced for this EA9-T7CL device specifically are its:
- 16.0W, 1.30A @ 12 VDC, 0.66A @ 24 VDC Power Consumption
- 4A Non-Replaceable Internal Fuse
- UL61010 (E157382), CE (EN61131-2), CUL Canadian C22.2, and RoHS (2011/65/EU) agency approvals
