Does the EA9-T6CL-R 6" 26 MB Touchscreen HMI have Ethernet capabilities?

No. This EA9-T6CL-R 6" 26 MB Touchscreen HMI is noticeably missing an Ethernet port.

DS200AAHA1	GE Turbine Control	Mark V

DS200AAHA1	GE Turbine Control	Mark V

Home Automation Direct C-More EA9 Series Touch Panel EA9-T6CL-R

❮

❯

About | Product Specifications | FAQs

EA9-T6CL-R

Q: Does the EA9-T6CL-R 6&quot; 26 MB Touchscreen HMI have Ethernet capabilities?

No. This EA9-T6CL-R 6&quot; 26 MB Touchscreen HMI is noticeably missing an Ethernet port.

4.00 (1)
Click a star to rate this product

4.00 (1)
Click a star to rate this product

The EA9-T6CL-R 6" 26 MB Touchscreen HMI

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a EA9-T6CL-R to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: EA9-T6CL-R
SKU: AD-59242

Manufacturer: Automation Direct
Series: C-More EA9 Series Touch Panel

Description
Repairs
Warranty
Manuals

EA9-T6CL-R Technical Specifications

Manufacturer	Automation Direct
Functional Description	EA9-T6CL-R 6" 26 MB Touchscreen HMI
Series	EA9 HMI
Ethernet 10/100 BaseT Communications	Not Available
Display Brightness	280 nits
Color Scale	65,536
Primary Serial Port	RS2342C, RS-422/485
Internal Fuse	4A

About the EA9-T6CL-R

This EA9-T6CL-R 6" 26 MB Touchscreen HMI or Human Machine Interface from Automation Direct was originally designed for the company's C-More line of EA9 Series offerings, with all the other products in this series acting as interfaces as well. This EA9-T6CL-R 6" 26 MB Touchscreen HMI has its own set of featured hardware, including its:

LED Backlight
6" Color TFT LCD
2 USB Ports
1 Memory Card Slot
1 Serial Port

This EA9-T6CL-R 6" 26 MB Touchscreen HMI product's singular memory card slot allows for the insertion of a Memory Card that enables this device to store up to 26 MB of total project memory, one of the smallest amounts for its greater series.

EA9-T6CL-R Basic Dimensions

While the EA9-T6CL-R Touchscreen HMI's hardware component inclusions and specifications are of course critical to its overall functionality, so too are the dimensions that allow it to be mlunted in industrial settings in the first place. This EA9-T6CL-R HMI's dimensions are:

a width of 8.08 inches
a height of 6.13 inches
a depth of 1.9 inches

Please note that the total depth of this EA9-T6CL-R 6" 26 MB Touchscreen HMI increases to 2.99 inches in total when the EA9-T6CL-R 6" 26 MB Touchscreen HMI is used alongside its respective AC/DC power converter.

Frequently Asked Questions about EA9-T6CL-R

Does the EA9-T6CL-R 6" 26 MB Touchscreen HMI have Ethernet capabilities?

No. This EA9-T6CL-R 6" 26 MB Touchscreen HMI is noticeably missing an Ethernet port.

What is the pixelation on this C-more device?

This particular HMI has a pixelation of 320 x 240 pixels; one of the smallest options for its particular AD series.

Reviews For EA9-T6CL-R

Internal Review

(5.0)

This EA9-T6CL-R Human-Machine Interface is characterized through its overall display size of six inches, which in turn leads to a smaller relative pixelation and a noticeable lack of a usual ethernet port. With this in mind, this EA9-T6CL-R still packs a punch through on-interface memory additions as well as its standard dual USB ports. - AX Control Lead Technician
