About the EA9-T10CL
The EA9-T10CL 10" LCD Touchscreen HMI featured on this page, as was mentioned above, is one of the larger Automation Direct products to feature as a member of their EA9 series under the C-more line, with an overall screen width of ten inches. Some of the other critical hardware traits and elements that the EA9-T10CL 10" LCD Touchscreen HMI utilizes in its assembly include its:
- 800 x 600 pixels pixelation
- 3 serial ports
- 1 Ethernet port
- 2 USB ports
- 1 audio line out
The audio line out that this EA9-T10CL 10" LCD Touchscreen HMI device features is not necessarily available to the rest of the EA9-T10CL 10" LCD Touchscreen HMI's C-More EA9 product series, so it can be something of a bonus. This EA9-T10CL 10" LCD Touchscreen HMI device's three total serial ports are not necessarily insulated, so be aware of any potentially-present surface voltages present on it.
EA9-T10CL Mounting Specifications
This EA9-T10CL Human Machine Interface specifically comes with an important to recognize series of specifications specifically pertaining to its mounting. For starters, this EA9-T10CL 10" Touchscreen comes with all of the needed mounting hardware; no auxiliary kit should be needed. Some of the other important mounting specifications for this C-more offering include its:
- 0.039 - 0.20 inch enclosure thickness range
- 63 - 77 oz-in mounting clip screw torque
- Metal material
