Woodward part 8440-1028 SPM-D21/PSVX Synchronizer and Load Control. 24 VDC power supply (+/-25 %), measuring inputs 400 VAC/1A, phase voltage matching.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Warranty: Learn More
Sell Surplus: Have a 8440-1028 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-1028
  • SKU: 84401028WO
  • Manufacturer: Woodward
  • Series: SPM-D21/PSVX

8440-1028

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Woodward part 8440-1028 SPM-D21/PSVX Synchronizer and Load Control. 24 VDC power supply (+/-25 %), measuring inputs 400 VAC/1A, phase voltage matching.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Warranty: Learn More
Sell Surplus: Have a 8440-1028 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-1028
  • SKU: 84401028WO
  • Manufacturer: Woodward
  • Series: SPM-D21/PSVX

8440-1028 Technical Specifications

Input Resistance approx. 68 kΩ
Intrinsic Consumption maximum of 10 W
Linear Measuring Range 1.3×V rated
Measuring Frequency 40 to 70 Hz
Power Supply 24 Vdc
Rated Phase-Ground Voltage 300 Vac
Rated Short-Time Current [1] 50×Irated, [5] 10×Irated

Product Description

The 8440-1028 unit is a synchronizer module and classified as a part of their SPM-D21/PSVX category of Two Breaker Synchronizer and Load Control units. The designation of this unit is the 8440-1028 model in this series. It is outfitted with the standard SPM-D21/PSVX synchronization features and breaker components. This unit has a generator circuit breaker and a mains circuit breaker and also includes power factor control and load control.

The 8440-1028 model is designed with synchronization capabilities for these circuit breakers, though can only sync them up one at a time. The phase matching and slip frequency syncing occurs with the voltage matching. The mains parallel functions have a real power control, a power factor control, and a soft shutdown feature.

The isolated features provide frequency control and voltage control. The dead bus feature provides closure for the circuit breaker modules within the 8440-1028. The 8440-1028 is equipped externally with a two-line text display unit, with LCD equipment, the LDC display on your controller will have a two-line display which is used for alarm and operation indication that is occurring on your controller.

While you are using your controller note that it has generator protection for over/under voltage, the ANSI number for this function will be fifty-nine or twenty-seven. The control output for this model includes a speed bias which can be configured to a Hz out of 500 and also has an adjustable voltage level.

If you have any questions regarding this model you can contact our sales department by phone number at (919) 372-8413 or by email at sales@axcontrol.com.
