Woodward Part 8440-1026 SPM-D21/PSVX Synchronizer and Load Control. Analog output of speed/load and voltage/power factor, and PMW output speed/load.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Warranty: Learn More
Sell Surplus: Have a 8440-1026 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-1026
  • SKU: 84401026WO
  • Manufacturer: Woodward
  • Series: SPM-D21/PSVX

8440-1026

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.67 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.67 (3)
  • Click a star to rate this product
Woodward Part 8440-1026 SPM-D21/PSVX Synchronizer and Load Control. Analog output of speed/load and voltage/power factor, and PMW output speed/load.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Warranty: Learn More
Sell Surplus: Have a 8440-1026 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-1026
  • SKU: 84401026WO
  • Manufacturer: Woodward
  • Series: SPM-D21/PSVX

8440-1026 Technical Specifications

Accuracy Class 1
Dimensions 144×72×122 mm
Humidity 95%, non-condensing
Input Resistance </= 68 kΩ
Intrinsic Consumption maximum of 10 W
Listings UL/cUL listed (voltages up to 300 Vac)
Measuring Frequency 40 to 70 Hz

Product Description

Unit model 8440-1026 is manufactured by Woodward inc and is part of the SPM line of synchronizers, specifically categorized as an SPM-D21/PSVX model. The Woodward SPM synchronizers are built to be integrated into industrial generator units that are three-phase, alternating current units, already outfitted with a speed control unit and a voltage regulator. These two components are not required that they be Woodward models, just that the setup and installation methods be similar.

The 8440-1026 is equipped with an array of operational features. The SPM-D21 models, such as this one provide automatic frequencies as well as voltage and phase matching which are used by the controller's analog or discrete output signals. Note that the 8440-1026 model uses microprocessor technology which allows for reliable and flexible operation.

It is crucial to note that when using your controller as a synchronizer with GCB and MCB operation the synchronization will occur separately, having the GCB and MCB potentially synchronize at the same time risks the controller being non-operational. The SPM-D21/PSVX series models are equipped with two control breakers as well as dead bus operation; if your controller has gone into dead bus operation the GCB or MCB will have closed on demand.

The mains parallel operation provides the unit with real power control, as well as true RMS power calculations. The isolated operation for this unit provides both voltage and frequency control.

AX Control is equipped to buy, sell, repair, and refurbish control models such as the 8440-1026, you can reach us by phone or email for a quote.
