Woodward Part 8440-1022 SPM-D21/PSV Two Breaker Synchronizer and Load Control. Features measuring/displaly of 2phase generator voltage, 1phase generator current, 2phase busbar voltage, and 3phase mains voltage. 24 VDC power supply, measuring inputs 120 VAC, ../1A.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 8440-1022 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

8440-1022

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
Woodward Part 8440-1022 SPM-D21/PSV Two Breaker Synchronizer and Load Control. Features measuring/displaly of 2phase generator voltage, 1phase generator current, 2phase busbar voltage, and 3phase mains voltage. 24 VDC power supply, measuring inputs 120 VAC, ../1A.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 8440-1022 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The 8440-1022 is a unit of the Woodward Inc. SPM-D21 series of two breaker synchronizer and load control modules. This line is built with a microprocessor based design, and intended for installation into generator systems that include a series of compatible parts. The 8440-1022 unit is able to provide an automatic frequency, phase, and voltage regulation and matching. The 8440-1022 is designed to provide a combined synchronization for a generator circuit breaker, as well as a mains circuit breaker, and a load and power factor control capability. The 8440-1022 unit’s synchronization occurs separate between the generator circuit breaker and the mains circuit breaker. The two-phase sensing is able to read and diagnose the generator system, utility bus, and mains. The 8440-1022 has four different operational modes which adjust the unit’s parameters within different methods and speeds. The four modes are labeled Run, Check, OFF, and Permissive. The mains parallel operation capabilities this unit is outfitted with includes Real power control, true RMS power calculation, as well as soft shutdown capability, and power factor control and setpoint by parameter. The standard operating features in this unit includes a two-line LCD display, which provides the operators with generator diagnostics and operational information. The 8440-1022 unit is built with the standard set of dimensions; 144 mm by 72 mm by 122 mm. This unit weighs at least 800 grams. AX Control Inc. is able to provide the 8440-1022 as a part of our inventory, either as unused surplus or used, reconditioned hardware. We cover each device with a comprehensive warranty that goes into effect upon purchase.

Repair Services For 8440-1022

Type Lead Time Price Action
Repair Service 1-2 weeks Ask Get Quote

Our highly skilled technicians can repair your 8440-1022. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
