Woodward 8440-1715 SPM-D11 synchronizer for use on one or three-phase generators. It combines synchronizing for one circuit breaker, load and power factor control or isochronous load sharing and generator protection.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8440-1715 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8440-1715
  • SKU: 84401715WO
  • Manufacturer: Woodward
  • Series: SPM-D11/LSXR

About the 8440-1715

The 8440-1715 is part of the Woodward SPM-D11 Series.  This unit is a load share synchronizer.  It is one of several SPM-D11 synchronizers available within the AX Control inventory.

The 8440-1715 is a microprocessor-based unit.  It can be used for one- or three-phase AC generators.  The synchronizer offers automatic frequency control and voltage and phase matching.  It can use either discrete or analog output bias signals.

The 8440-1715 is Ul/cUL listed and CE marked.  It can be configured using the unit’s front panel or it can be configured through a connected PC.   Because of the unit’s microprocessor technology, it offers flexible and reliable operating options, including adjustable language (English or German,) control and breaker state indication, and synchroscope.   The unit has a two-line LCD display on its front panel that allows the user to see alarm indication and operations locally.  The unit also offers dead bus operation(the closing of a breaker on demand.)

The 8440-1715 uses a 12/24 VDC power supply.  The unit’s dimensions are 144 mm x 72 mm x 122 mm.  Connections are made by screw/plug terminals depending on the type of connector used.

For a more detailed view of the 8440-1715, please refer to the original documentation from the OEM.  This may include user guides or product manuals.  Datasheets may also help.   We suggest reading through all handling and wiring information before unboxing your replacement part in order to protect yourself and the integrity of your purchase.

AX Control provides replacement automation parts to companies around the globe.  Let us know what we can do to help you.


Repair Services For 8440-1715

Type Lead Time Price Action
Repair Service 1-2 weeks $949

Our highly skilled technicians can repair your 8440-1715. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

8440-1715 Manuals, White Papers, Data Sheets, and Troubleshooting
