Woodward Part 5448-894 SPM-D Synchronizer. 2 VDC Power Supply, 2phase generator voltage and 2phase busbar voltage measuring/display.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 5448-894 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

5448-894

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
Woodward Part 5448-894 SPM-D Synchronizer. 2 VDC Power Supply, 2phase generator voltage and 2phase busbar voltage measuring/display.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a 5448-894 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

5448-894 Technical Specifications

Ambient Humidity 95%, not condensing
Manufacturer Woodward
Max. change after endurance test < 0.3%
Max. Switching Voltage 250 Vac
Power Supply 24 Vdc (±25%)
Rated Short Time Current 10 x In
Tempreature Coefficient 15 ppm/K

Product Description

This model is the 5448-89 in the SPM-D Synchronizer series. This unit is outfitted with the standard microprocessor-based design and features. The 5448-894 is able to provide the generator control system with an automatic frequency and phase slip, utilizing the analog output to process the biased signals.The 5448-894 model is outfitted with the standard SPM-D Mains Failure Recognition and Generation Protection. This includes a three phase, mains over and under voltage monitoring capabilities, as well as single phase over/under voltage monitoring capabilities. The other features include over/under frequency monitoring, phase shift monitoring, and then reverse and overload power monitoring.

The 5448-894 model has the following electrical specifications: the measuring voltage is 110 V/AC, and the measuring current ranges from 40 to 70 hertz. The operational power supply is nominally 24 V/DC, though the range is from 18 to 32 V/DC. The power consumption is 10 W at max. When operational, the ambient temperature this unit requires to function in is -20 to 70 degrees C, and the relative humidity it can withstand is up to 95 percent.The 5448-894’s dimensions measure out to 144 mm by 72 mm by 122 mm, and weighs at least 800 grams. AX Control is ready to buy and sell these parts as well as repair and resell our products as well.

Reviews For 5448-894
Internal Review

Well designed and put together. Does what it's supposed to do and does it well. Tested before shipped and met expectations, additionally works as described. Make sure to thoroughly read manual before installation.-AX Control Tech Team.

Repair Services For 5448-894

Type Lead Time Price Action
Repair Service 1-2 weeks $1144

Our highly skilled technicians can repair your 5448-894. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
