5448-891

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Woodward Part 5448-891 SPM-D Synchronizer. 2 VDC Power Supply, 2phase generator voltage and 2phase busbar voltage measuring/display. Measuring inputs 1 VAC. Featured options: VJH, UF, R2, Discrete Speed/Voltage.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Warranty: Learn More
Sell Surplus: Have a 5448-891 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5448-891
  • SKU: 5448891WO
  • Manufacturer: Woodward
  • Series: SPM-D Synchronizer

5448-891

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Woodward Part 5448-891 SPM-D Synchronizer. 2 VDC Power Supply, 2phase generator voltage and 2phase busbar voltage measuring/display. Measuring inputs 1 VAC. Featured options: VJH, UF, R2, Discrete Speed/Voltage.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Warranty: Learn More
Sell Surplus: Have a 5448-891 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5448-891
  • SKU: 5448891WO
  • Manufacturer: Woodward
  • Series: SPM-D Synchronizer

5448-891 Technical Specifications

Ambient Temp. -20 - 70C
Digital Inputs Metallically Separated
Insulation voltage 2,200Veff
Manufacturer WoodWard
Max. change after endurance test < 0.3%
Measuring Voltage 110 Vac
Resolution PWM 8 Bit

Product Description

This unit 5448-891 is a part of the SPM-D Synchronizer series. The 5448-891 digital synchronizer is designed to be integrated into a three-phase, Alternating Current generator. This model has several options for operating, such as the R2, UF, and VJH options. The R2 is able to provide users with the ability to reverse and can monitor reduced and overloaded power. The UF option is 1 ph, and provides Generator over and under voltage monitoring, as well as over and under frequency monitoring. The VJH option also provides this as a main functionality, as well as the phase shift monitoring.

The 5448-891 unit is able to provide generators with automatic frequency, phase, and voltage matching, using either the analog or discrete output bias signals. This unit is protected with a user selected password, and is configurable either through the human/machine interface, or through the USB connected ToolKit configuration module. The standard benefits of installing the 5448-891 as a generator synchronizer is the compatibility within a large range of units, and works together with automatic voltage regulators and circuit breakers. This unit is programmed with a sensor for true RMS input into the generator, and has a front face, LED Synchroscope for effective commissioning. AX Control INC. is able and willing to: Buy, sell, fix, and resell this machine along with those like it along with many more.

Reviews For 5448-891
Internal Review

Good product that gets the job done and does it well. However, it would be wise to make sure that whoever is working on as well as installing it. Is certified in some manner and is fully aware of what they are doing.- AX Control Tech Team.

Repair Services For 5448-891

Type Lead Time Price Action
Repair Service 1-2 weeks $931

Our highly skilled technicians can repair your 5448-891. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
