8237-1369

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
The 8237-1369 provides various pre-defined test routines including an automated periodic test routine to assist users with verifying system operation.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8237-1369 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8237-1369
  • SKU: 82371369WO
  • Manufacturer: Woodward
  • Series: ProTech-GII Overspeed Protection

8237-1369

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
The 8237-1369 provides various pre-defined test routines including an automated periodic test routine to assist users with verifying system operation.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 8237-1369 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8237-1369
  • SKU: 82371369WO
  • Manufacturer: Woodward
  • Series: ProTech-GII Overspeed Protection

8237-1369 Technical Specifications

Dimensions 330 x 445 x 159 mm
Electromagnetic Compatibility Emissions: EN61000-6-4 Immunity: EN61000-6-2
Enclosure Type IP56 when installed correctly
Features Reverse Polarity Protection for DC
High Input Voltage Nominal 115 Vac / 240 Vac / 125 Vdc
Keypad/Display 15 Keys per module
Low Input Voltage Nominal 24 Vdc
Operating Temperature –20 to +60 °C (–4 to +140 °F)
Relative Humidity Up to 95% (non-condensing)
Storage Temperature –20 to +65 °C (–4 to +158 °F)
Weight 23 lbs before shipping

Product Description

Model 8237-1369 is an over speed detection device that can be configured to work with various turbines. It is part of the ProTech-GII series from Woodward and fits any size of hydro, steam, or gas turbine. In the event of over acceleration, this product will safely shut down the system. Speed readouts for this device are between 4 and 20 mA, and it uses Modbus communication relays. In addition to acceleration detection, model 8237-1369 also uses MPU detection. This product performs routine tests to make sure each module is functioning properly. A conformal coating material makes this speed safety device resistant to sulfur contamination, as well as H2S and SO2 gases.

The product uses a triple modular design, with A, B, and C modules. This makes it possible to replace one aspect of the model while it is powered on and running. The panel mount device uses 2 out of 3 voted architecture. Model 8237-1369 uses both high voltage and low voltage power input. This product has been discontinued by Woodward but is still supplied through AX Control. It can be configured to work on any size turbine to safely shut it down if it over accelerates.

Reviews For 8237-1369
Internal Review

Due to Woodward's model 8237-1369 market availability, finding a direct replacement unit will be hard. AX Control generally tries to keep a surplus of parts for this series in stock however, we can only recommend an upgrade or repair service for this model. - AX Control Technicians

Repair Services For 8237-1369

Type Lead Time Price Action
Repair Service 1-2 weeks $4525

Our highly skilled technicians can repair your 8237-1369. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
