Unit 9905-903 from Woodward ProTech 203 Overspeed Protection. 24Vdc Input, Lockable Enclosure, Remote Reset, and CPU/MPU Fail Indication.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 9905-903 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 9905-903
  • SKU: 9905903WO
  • Manufacturer: Woodward
  • Series: ProTech 203 Overspeed Protection

9905-903

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.8 (5)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.8 (5)
  • Click a star to rate this product
Unit 9905-903 from Woodward ProTech 203 Overspeed Protection. 24Vdc Input, Lockable Enclosure, Remote Reset, and CPU/MPU Fail Indication.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 9905-903 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 9905-903
  • SKU: 9905903WO
  • Manufacturer: Woodward
  • Series: ProTech 203 Overspeed Protection

9905-903 Technical Specifications

Dimensions W482.6 x H310.4 x D142.7 (with knobs and key)
Display Operating Temperature –15 to +60 °C (5 to 140 °F)
Features Remote Overspeed Test
Input Voltage 24 Vdc
Manual 85201
Manufacturer Woodward
NEMA Rating 4
Operating Temperature –25 to +60 °C (–13 to +140 °F)
Standards for Humidity US MIL-STD-810D, Method 507.2, Procedure II
Weight Approx 7.3Kg

Product Description

This dual relay overspeed protection device has three displays on the front panel, one for each of the three speed-sensing units in the enclosure. Each unit also has its own keypad and functional status LEDs. The internal units are configured for two-out-three hardware voting. The three units within the ProTech 9905-903 dual relay overspeed protection device are programmed individually but must be programmed with identical trip points for proper functioning.



9905-903 units are programmed using the display and keypad on the front panel. PROGRAM mode access is limited to those with key access to the NEMA 4 enclosure. A few of the tunable parameters available with the 9905-903 device are trip speed setpoint, MPU failed setpoint, and MPU failed timeout. A complete list of tunable parameters as well as programming instructions can be found in Woodward ProTech 203 Overspeed Protection System Manual 85201.



There are nine parameters operators can view one at a time on each of the three LCD displays on the 9905-903’s front panel. The current speed for the corresponding speed-sensing unit is the default first parameter shown. These front panel LCDs are also used to display error messages, including MPU FAILED, NO RESET, MPU>TRIP SETPT, and more.



Woodward Manual 85201 has more specifications for the 9905-203 overspeed device as well as location requirements, environmental requirements, etc., but there are a few more manuals Woodward recommends consulting before installing this system. Manuals 82715, 82510, 50532, and 85562 all contain information relevant to the proper handling and operation of this ProTech 203 dual relay model.
