Woodward Load Sharing Module Part 9907-174. This part features PWM/GenDec output types and 115/230 VAC supply voltage. Allows load sharing with Woodward and non-Woodward equipped engines and provides isochronous and droop load sharing.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 9907-174 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 9907-174
  • SKU: 9907174WO
  • Manufacturer: Woodward
  • Series: Load Sharing Module

9907-174

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Woodward Load Sharing Module Part 9907-174. This part features PWM/GenDec output types and 115/230 VAC supply voltage. Allows load sharing with Woodward and non-Woodward equipped engines and provides isochronous and droop load sharing.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a 9907-174 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 9907-174
  • SKU: 9907174WO
  • Manufacturer: Woodward
  • Series: Load Sharing Module

9907-174 Technical Specifications

3-Phase PT Inputs 95-130 Vac
DC Models 18-32 Vdc
Dimensions 273.6 mm X 59.2 mm X 214.1 mm
Manufacturer Woodward
Operation Temp -40 - 158 F
Output to Speed Control + 0.5 to + 4.5 Vdc analog
Shock 40 G

Product Description

This setup needs a digital speed control unit, utilizing a PWM, or pulse width modulated waveform input. Once installed, the 9907-174 LSM unit allows the generator to use other Woodward Inc. hardware to aid in regulating power levels. In addition, there are other functions such as. This unit acts as a gateway to set up several individual modules onto your generators, such as the SPM-A and SPM-D synchronizers, a paralleling phase switch, an import/export control, and precision frequency control. This unit is outfitted to provide generators with the adjustment capabilities needed to help streamline the process of generating power.

There are two key settings programmed into the 9907-174, the droop and load gain settings. The droop provides output reducing between no load and full load conditions, and then the load gain is able to adjust the load even while multiple generators are paralleled. The 9907-174 model is designed with a standard set of specifications, such as the power intake required for it to run at optimal speeds. The nominal voltage needed is 24 volts of direct current, but a minimum of 18 is needed and can take up to 32 V/DC before damage occurs. Environmentally, the 9907-174 module needs to be installed in an industrial workplace setting that is in a temperature between the acceptable range is between low as -40 C/F to as hot as 70 C, or 158 F. AX Control is adapt to buy, fix, sell, and resell this product as well as others.

Reviews For 9907-174
Internal Review

Its positive test results demonstrate its ability to perform its job with high remarks. It should be noted however, that to achieve this it is needs to be installed by aa certified supervisor as. Additionally it needs to be operated by an operator with working knowledge on the part. - AX Control INC. Tech Team.

Repair Services For 9907-174

Type Lead Time Price Action
Repair Service 1-2 weeks $902

Our highly skilled technicians can repair your 9907-174. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
