Woodward Load Sharing Module Part 9907-173. This part features +/-3 VDC analog output type and 115/230 VAC supply voltage. Allows load sharing with Woodward and non-Woodward equipped engines and provides isochronous and droop load sharing.

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a 9907-173 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 9907-173
  • SKU: 9907173WO
  • Manufacturer: Woodward
  • Series: Load Sharing Module

9907-173

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Woodward Load Sharing Module Part 9907-173. This part features +/-3 VDC analog output type and 115/230 VAC supply voltage. Allows load sharing with Woodward and non-Woodward equipped engines and provides isochronous and droop load sharing.

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a 9907-173 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 9907-173
  • SKU: 9907173WO
  • Manufacturer: Woodward
  • Series: Load Sharing Module

9907-173 Technical Specifications

3-Phase CT Inputs 3-7 Arms at full load.
Dimensions 273.6 mm X 59.2 mm X 214.1 mm
Droop Provides 0-10% speed reduction
Humidity 95% RH,
Manufacturer Woodward
Overvolatge Category Category III
Shock 40 G

Product Description

This unit belongs as a part of the Woodward Inc Load Sharing units. This unit is designated as the 9907-173 model of isochronous and droop load sharing unit. These units were developed and produced to be attached and installed onto Caterpillar model engines, equipped with their similarly produced digital speed components. These engines process a Pulse-Width Modulated input. When a Woodward Load Sharing module is attached to it, this allows the integration of other Woodward-produced parts as well. It also divides the load sharing between the Caterpillar engines and speed control module, and the Woodward electronic controls.

The power supply intake that this module requires ranges between the minimum intake of 18 to 32 V/DC, or alternatively, 5 Watts. It is protected from reverse voltage up to -32 V/DC, as well as under voltage and overvoltage up to 80 V/DC. There are both PT and CT three-phase inputs. The PT inputs require 100 to 240 V/AC line to line, while the CT inputs need 3 to 7 A Rms at full load. It should be noted that this device is meant to only be in service with the incorporation of an engine prime mover system that meets the requirements of the stated Directive as well as the CE mark.

AX Control INC can provide services to this machine and others like it such as: Buying, Selling, Repairing, and Reselling.

Reviews For 9907-173
Internal Review

Was tested, and met expectations. However this was done by one of our own knowledgeable technicians. So it is imperative that whoever installs/uses this machine needs to have a solid understanding of its workings. AX Control INC. Tech Team.

Repair Services For 9907-173

Type Lead Time Price Action
Repair Service 1-2 weeks $884

Our highly skilled technicians can repair your 9907-173. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
