Woodward Isochronous Speed Control Model 8290-184 is designed to be in conjunction with diesel or turbine prime movers and has a system battery voltage of 24 VDC. This model must be used in a 3000-6000 Hz range and has a start fuel limit.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8290-184 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8290-184
  • SKU: 8290184WO
  • Manufacturer: Woodward
  • Series: EPG Electrically Powered Governor

8290-184 Technical Specifications

Magnetic Pickup Input Minimum 1.5 VRMS
Manuals 25182, 04106, 50530, 82327, and 82329
Maximum Terminal Shaft Position for Start Fuel Limit 95%
Model Type Speed Control, Isochronous
Prime Mover Type Diesel or Gas Turbine
VDC Power Supply 24

About the 8290-184

Model 8290-184 is a speed control device from Woodward. This product is in the Electrically Powered Governor series and is compatible with specific actuators from the same manufacturer. Model 8290-184 can be used with actuators 1712, 1724, 512, and 524. It is designed to work with prime movers powered by gasoline or gas. This model is made to work as part of a full EPG system. These systems include a speed control device, an actuator, and magnetic pickup.

This speed control device has a 24-volt battery voltage, and VDC ranges from 20 VDC to 32 VDC. It uses a 5A battery charger. The device should be installed with 12 AWG and 14 AWG wiring (depending on length). The ambient temperature range for product 8290-184 is -40 to 167 degrees Fahrenheit. It operates with a 10 A slow blow fuse and is compliant with EU Directives. It consumes up to 95 watts of power, and can be mounted on the engine it will work with.

This speed control device uses a start fuel limit, and can also be used with an optional ramp generator. Model 8290-184 has been discontinued by Woodward, but can be found here at AX Control Inc. AX Control will buy, sell, and repair this device. All purchases through us come standard with a three-year warranty. For more information on this unit, please refer to the multiple manuals, data sheets, and drawings found in our "Manuals" tab above.

Reviews For 8290-184

Internal Review
(4.0)

The Isochronous Speed Control 8290-184 model is used in conjunction with turbine prime movers. This model has a start fuel limit that helps control the smoke on the turbine. - AX Control Tech Team

Repair Services For 8290-184

Type Lead Time Price Action
Repair Service 1-2 weeks $1504

Our highly skilled technicians can repair your 8290-184. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
