The Speed Control with Position Feedback model 8290-149 can be used with a number of actuators manufactured by Woodward and has a magnetic pickup of 1.5 VRMS.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8290-149 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8290-149
  • SKU: 8290149WO
  • Manufacturer: Woodward
  • Series: EPG Electrically Powered Governor

8290-149 Technical Specifications

Actuators Used 1724/1712, 512/524 and 4024
Ambient Temperature Range -40 to +167 °F
Fuse Rating 10 A Slow-Blow Fuse
Manuals 50530, 04106, 82327, and 82329
Model Type Speed Control with Position Feedback
Series EPG, Electrically Powered Governor
Speed Trim Optional, Use1 KW potentiometer for ±2.5% speed change

Product Description

Model 8290-149 is a Woodward speed control device equipped with position feedback. It is part of the Electrically Powered Governor series and works on prime movers. It is part of a complete EPG system, which also includes magnetic pickup and an actuator. Product 8290-149 is only compatible with certain types of Woodward actuators. This device can be used with actuators 4024, 512/524, and 1724/1712.

Details about this speed control device include;

  • Magnetic pickup of 1.5 VRMS.
  • 10A slow-blow fuse.
  • Optional use of 1 KW potentiometer.
  • Ambient temperature range of -40 to 167 degrees Fahrenheit.
  • Compliant with EU Directive.
  • Optional use of ramp generator and speed trim
  • Compatible with load-sharing accessories.
  • Switch-selected dynamics.

Model 8290-149 weighs around one pound, and should be installed near the actuator and magnetic pickup it will be used with. When installing the device 14 AWG and 12 AWG wires can be used. It can be used with prime movers that are powered by diesel, gasoline, or gas. No mechanical drive or hydraulic oil supply is needed for operating this speed control device. It can currently be found through AX Control, despite being discontinued by Woodward. AX Control will buy, sell, and even repair these products. A three-year warranty comes standard with each purchase.

Reviews For 8290-149

Internal Review
(5.0)

Speed Control with Position Feedback model 8290-149 can be used with any of the actuator models within the Electrically Powered Governor Series. All information needed to power and wire this model can be found in the attached manuals on this page. - AX Control Technician
