Woodward INC EPG System Actuator Drive Model 8290-134 can be used with a number of actuators, 724, 1724, 512, 1724, and 4024. The model can be used unattended. Part number 8290-133 can be used with prime movers that do not have a hydraulic oil supply or any type of mechanical driver.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8290-134 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8290-134
  • SKU: 8290134WO
  • Manufacturer: Woodward
  • Series: EPG Electrically Powered Governor

8290-134 Technical Specifications

Actuators Used 1712/1724, 512/524 and 4024
Battery Charger Capability minimum 5 A
Manuals 82038, 04106, 82329, and 50530
Model Type EPG Actuator Driver
Series Electrically Powered Governor, EPG
System Battery Voltage 24 Volt
VDC Range min. 20 VDC to max. 32 VDC

About the 8290-134

A Woodward actuator driver from the Electrically Powered Governor series is model 8290-134. It is made to be used on prime movers and can be used on multiple models of actuators. The actuators of this device are compatible with models 4024, 1724, 512, and 724. No mechanical drive or hydraulic supply is needed to operate this Woodward device.

The actuator driver model 8290-134 is designed to be used while unattended. The VDC range of this product has a minimum of 20 VDC and a maximum of 32 VDC. The minimum battery charger capability is 5A. The system battery voltage is 24 volts, and the maximum power consumption is 95 watts.

When installing this product, 12 AWG and 14 AWG wiring can be used. The temperature range is between -40 and 167 degrees Fahrenheit. This device can be used on prime movers that operate with gas, gasoline, or diesel. It is compliant with EU Directives and is designed with cast aluminum. It can also be used with load-sharing accessories. While model 8290-134 has been discontinued through the original manufacturer, it is currently available with AX Control. These devices can be bought, sold, or repaired through AX Control, and repairs are given a three-year-long warranty.

Reviews For 8290-134

Internal Review
(5.0)

Model 8290-134 is an EPG Actuator Driver produced by Woodward that operates at a standard 24-volts for the system battery. When this model is being wired, please note that the allowable wire length with the 4024 model is 22 ft. for 12 AWG and 8 ft. for 14 AWG. - AX Control Technician

Repair Services For 8290-134

Type Lead Time Price Action
Repair Service 1-2 weeks $1629

Our highly skilled technicians can repair your 8290-134. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
