8290-133

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Woodward Electrically Powered Governor Actuator Drive Model 8290-133 can be used with a 4024 model that requires a larger terminal lever of .500-36 serrations. Please note that the total allowable wire length for 4024 models is 22 ft. for 12 AWG and 8 ft. for 14 AWG.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8290-133 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8290-133
  • SKU: 8290133WO
  • Manufacturer: Woodward
  • Series: EPG Electrically Powered Governor

8290-133 Technical Specifications

Fitted Number Ring Terminal 8
Fuse 10 A Slow-Blow Fuse
Manufacturer Woodward Inc
Model Type EPG Actuator Driver
Series Electrically Powered Governor, EPG
Wiring Length from Control to Actuator 4 ft. (14 AWG) and 12 ft. (12 AWG)

Product Description

Model 8290-133 was manufactured by Woodward, and belongs to the Electrically Powered Governor series. This product is an actuator driver that can be used as part of a full EPG system. These systems and this device are designed to work on prime movers without the need for a hydraulic oil supply or mechanical drive.

Product 8290-133 is compliant with EU Directive, just like the other products belonging to this Woodward series. A cast aluminum design makes it resistant to heat and long-lasting. It has been discontinued, but can be found with AX Control.

Specifications for model 8290-133 include;

  • 10 A Slow-Blow Fuse.
  • 8 fitted ring terminals.
  • Compatible with 12 AWG and 14 AWG wire.
  • Maximum 12 AWG length of 22 feet and maximum 14 AWG length of 8 feet.
  • Temperature range of -40 to 167 degrees Fahrenheit.
  • Operates with 4024 model.
  • Minimum magnetic input of 1.5 VRMS.

When creating a full EPG system, an actuator, speed control device, and magnetic pickup must be used together. The use of speed trim and a ramp generator is optional. AX Control is able to buy and sell, in addition to repair, product 8290-133. Any repairs that come from AX Control are also given a warranty good for three years.

Reviews For 8290-133

Internal Review
(5.0)

The Electrically Powered Governor Actuator Driver model 8290-133 is best used independently, typically these controls are built with dynamics that are designed and best used in specific engine applications. - AX Control Technician

Repair Services For 8290-133

Type Lead Time Price Action
Repair Service 1-2 weeks $1303

Our highly skilled technicians can repair your 8290-133. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
