8290-103

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
The Woodward EPG Series model 8290-103 is a speed control equipped with position feedback. This model can be used with any of the actuators. The 8290-133 model has a steady state speed band that will typically maintain a ±1/4 of 1% of the rated speed.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8290-103 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8290-103
  • SKU: 8290103WO
  • Manufacturer: Woodward
  • Series: EPG Electrically Powered Governor

8290-103 Technical Specifications

Magnetic Pickup Input Minimum 1.5 VRMS
Manuals 82038, 04106, 50530, 82329
Manufacturer Woodward Inc
Model Type Speed Control with Position Feedback
Mounting In Any Configuration
Prime Mover Type Gas/Gasoline Engine and Diesel/Gas Turbine
Speed Trim Use a 2 KW potentiometer for a speed change of ±5%

Product Description

Woodward product 8290-103 is a speed control device that can be used on various types of prime movers. This device is compatible with gas or gasoline engines and diesel or gas turbines. The speed control model can be mounted in any configuration and works with position feedback. It uses a 2 KW potentiometer speed trim. Model 8290-103 is part of the Electrically Powered Governor series and is compatible to work with any model of actuators. It can operate with all of the actuators belonging to this Woodward series. Adding this device to an actuator and magnetic pickup creates a full EPG system.

The temperature range when using this product should stay from -40 to 167 degrees Fahrenheit. Similar to other speed control devices from the Woodward series, this model is EU Directive Compliant. The minimum magnetic pickup input is 1.5 VRMS. It can be installed with 12AWG and 14AWG wires. When mounted, the device should be in a protected and ventilated space, close to both the actuator and battery. Even though Woodward has discontinued the manufacturing of product 8290-103, it can currently be found through sources like AX Control. AX Control will sell, buy, and repair these speed control devices, and any repairs are given a three-year warranty.

Reviews For 8290-103

Internal Review
(4.0)

The 8290-103 model has limited information on it due to its obsolescence. If you have any questions regarding this model feel free to reach out and our team can do their best to help you regarding your questions. - AX Control Technician

Repair Services For 8290-103

Type Lead Time Price Action
Repair Service 1-2 weeks $1591

Our highly skilled technicians can repair your 8290-103. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
