The 8290-077 Single-phase Droop Control Governor from Woodward

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 8290-077 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 8290-077
SKU: WO-57207

Manufacturer: Woodward
Series: EPG Electrically Powered Governor

Description
Repairs
Warranty
Manuals

8290-077 Technical Specifications

Magnetic Pickup Input	Minimum 1.5 VRMS
Manuals	04106, 50530, 82327, and 82329
Prime Mover Type	Gas and/or Diesel Turbine
Series	Electrically Powered Governor, EPG
System Battery Voltage	24 Volt
Wire Length from Battery to Control for 524 and 1724	35 ft. for 14 AWG and 75 ft. for 12 AWG

About the 8290-077

Woodward model 8290-077 is a speed control device that belongs to the Electrically Powered Governor series. It is a single-phase droop control device, designed to be compliant with EU Directive. Model 8290-077 works with diesel or gas-powered turbines. Additional information about this Woodward device includes;

Minimum magnetic pickup input of 1.5 VRMS
Compatible with 2500 Load Sensor
A system battery voltage of 24 volts
Maximum power consumption of 95 watts
7 A charger compatible
Temperature range of -40 to 167 degrees Fahrenheit

Adding this speed control device to an actuator and magnetic pickup will create a full EPG system. Model 8290-077 can be mounted directly to the prime mover that it will work on. It should be kept away from high-heat products, away from moving devices, and in a well-ventilated location. This product can also work with load-sharing accessories. Even though the speed control device model 8290-077 has been discontinued by Woodward, it can be found through sources such as AX Control. This product can be repaired, bought, or sold with AX Control. Any repairs are also given a three-year warranty.

Frequently Asked Questions about 8290-077

Is the 8290-077 Single-phase Droop Control Governor's backplane lifted?

Yes. There is a significant amount of space between the 8290-077 Single-phase Droop Control Governor's backplane bottom and its base circuit board.

How many installation holes does the 8290-077 feature?

This 8290-077 unit has four total installation holes, one per corner.

Reviews For 8290-077

Internal Review

(5.0)

Electrically Powered Governor Model 8290-077 has a magnetic pickup input that must be must a minimum of 1.5 VRMS and will be at 100 Hz when cracking. This model is the best model to be used if a single-phase droop control is needed. - AX Control Technician

Repair Services For 8290-077

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$1701

Our highly skilled technicians can repair your 8290-077. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

48-72hr Rush Repair
Detailed Repair Reports
AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.

All PLCs, HMIs, and Turbine Control Boards:	3 Years
All AC/DC and Servo Drives:	2 Years
All Motors:	1 Year
