8290-074

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
Woodward model 8290-074 is part of the Electrically Powered Governors Series. The model is used with gasoline and gas engine prime movers at 1500-3000 Hz. Please note that model 8290-074 is a single-phase droop controller and needs to be used with either a model 1724 (8256-016) or model 524 (8256-021) actuator.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8290-074 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8290-074
  • SKU: 8290074WO
  • Manufacturer: Woodward
  • Series: EPG Electrically Powered Governor

8290-074 Technical Specifications

Fuse Rating 10 A Slow-Blow Fuse
Magnetic Pickup Input Minimum 1.5 VRMS
Model Type Single-Phase Droop Control
Prime Mover Type Gas/Gasoline Engine
System Battery Voltage 24-Volt
Total Allowable Wiring for 524/1724 Models 150 ft for 12 AWG, and/or 70 ft for 14 AWG
Work Output Range for 524 and 1724 Models 1.0 J (.75 ft.-lb.) to 2.3 J (1.7 ft.-lb.)

About the 8290-074

Model 8290-074 is from the Woodward manufacturer, and works as a speed control device in an EPG system. This device is in the Electrically Powered Governor series and has been discontinued. Adding this model to an actuator and magnetic pickup makes an EPG system that can be used with prime movers. These systems do not require the use of a hydraulic supply or mechanical drive, making them simple and easy to operate. Product 8290-074 can be used with actuator models 8256-021 and 8256-016 and is only compatible with gas or gasoline prime movers. It uses a 24-volt system battery voltage, with a steady-state-current consumption maximum of 3 amps.

The speed range for this model is 1500 to 3000 Hz, and the operating temperature should remain between -40 and 167 degrees Fahrenheit. This device can be mounted directly on the prime mover but should be in a protected area away from moving parts and high-heat products. It should also be installed with plenty of ventilation, and close to the actuator and battery of the mover. While Woodward has discontinued model 8290-074 it is available through AX Control. AX Control can sell, buy, or repair this speed control device.

Reviews For 8290-074

Internal Review
(5.0)

The 8290-074 model is the perfect model to be used as a single-phase droop control, the model must be used with an actuator, and the actuator used must be a 524 or 1724 model. - AX Control Technician

Repair Services For 8290-074

Type Lead Time Price Action
Repair Service 1-2 weeks $1508

Our highly skilled technicians can repair your 8290-074. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
