8290-067 Image One
3 year warranty

8290-067 Image 1
8290-067 Image 2
8290-067 Image 3
8290-067 Image 4

8290-067

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Single-Phase Droop Controller 8290-067 operates within a required speed range of 750-1500 Hz alongside the 8256-017 and 8256-022 actuators. The 8290-067 model operates on a system battery voltage of 12-V, and will only work with diesel/gas turbines.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 8290-067 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 8290-067
  • SKU: 8290067WO
  • Manufacturer: Woodward
  • Series: EPG Electrically Powered Governor

8290-067 Technical Specifications

Battery Charger Capability min. 7 A
Manufacturer Woodward Inc
Model Type Single-Phase Droop Control
Power Consumption max. 60 W
Prime Mover Type Diesel and Gas Turbine
Required Speed Range 750-1500 Hz
Series Electrically Powered Governor, EPG

Product Description

Droop speed control device 8290-067 from Woodward as one part of a full EPG system. The Electrically Powered Governor series controllers must be combined with an actuator and magnetic pick-up to create a complete EPG system. Product 8290-067 is compatible with the actuator models 8256-017 and 8256-022. It should be mounted near the actuator and battery and can be used with 12 AWG and 14 AWG wires. The device should be mounted in a covered area and can be placed on the prime mover. This speed control product can be used on turbines powered by gas or diesel.

Additional details about model 8290-067 include;

  • Operating temperature of -40 to 167 degrees Fahrenheit.
  • System battery voltage of 12V.
  • Speed range of 750 to 1500 Hz.
  • EU Directive Compliant.
  • Does not need a mechanical drive or hydraulic supply to operate.

In order for this speed control device to properly operate it must be used with a compatible actuator. It should always be cooled down with natural air circulation, so should be installed in a place with proper ventilation. Woodward has discontinued product 8290-067, but can currently be bought, sold, or repaired through AX Control. Any AX Control repairs are provided with a three-year warranty.

Reviews For 8290-067

Internal Review
(5.0)

Woodward model 8290-067 is a single-phase droop control that must have a 10 A slow-blow fuse/circuit breaker installed within the non-grounded battery lead, the battery must be led directly to the controller and not through distribution points. - AX Control Tech Team

Repair Services For 8290-067

Type Lead Time Price Action
Repair Service 1-2 weeks $1078

Our highly skilled technicians can repair your 8290-067. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
