Woodward Inc's Electrically Powered Governor part 8256-086 is labeled as a 524 model. This model operates on a 24-volt battery with a max 95 W power consumption. Model 8256-086 will have a 50 KA potentiometer that is used with the idle speed feature.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 8256-086 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

8256-086

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Woodward Inc's Electrically Powered Governor part 8256-086 is labeled as a 524 model. This model operates on a 24-volt battery with a max 95 W power consumption. Model 8256-086 will have a 50 KA potentiometer that is used with the idle speed feature.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 8256-086 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

8256-086 Technical Specifications

Battery Voltage Measuring Value 24-Volt
Fuse and Wiring 10 A Slow-Blow Fuse
Maximum Power Consumption 95 W
Mounting Location Engine Skid Mountable in Any Attitude
Output Shaft 0.375\"-36 SAE serrated shaft on each end
Start Fuel Limit Adjusted by an Internal 10-Turn Potentiometer

Product Description

Model 8256-086 is an actuator from Woodward. It comes out of the Electrically Powered Governor series and will make up a full EPG system when combined with magnetic pickup and speed control. This actuator can be used on prime movers with low-friction and low-mass and is designed to ensure it can handle high heat. It is equipped with a start fuel limit and a safety circuit. The product also uses a load sensor and auxiliary input to make sure the model is operating correctly.

This actuator is designed with seal bearings and has a cast aluminum construction. This makes the model long-lasting and corrosive resistance. The sealed bearings keep users from having to perform maintenance on the actuator. Model 8256-086 will consume up to 95 watts of power, but no more, and is powered through a 24-volt battery. This actuator can be mounted to the engine skid and uses a 10 A slow-blow fuse. Model 8256-086 uses an idle speed feature with a 50 KA potentiometer.

Each end of the output shaft is serrated. This actuator model should not be used in temperatures that exceed 167 degrees Fahrenheit. Product 8256-086 has been discontinued by Woodward, but can be bought, sold, or repaired with AX Control.

Reviews For 8256-086
Internal Review

Model number 8256-086 does not have much information on it due to its obsolescence but information can be found in the 04106 Product Specification Manual. If questions arise feel free to contact us and our team can do its best to help you. - AX Control Tech Team

Repair Services For 8256-086

Type Lead Time Price Action
Repair Service 1-2 weeks $1689

Our highly skilled technicians can repair your 8256-086. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
