Woodward Inc's easYgen-3500XT-P2 Genset Controller is used for complex paralleling operations. The model can be used with several power generation topologies. The easYgen-3500XT-P2 model can be used with LS-6XT breaker models, 32 of the 3500XT-P2 models and 32 of the LS-6XT breakers can be used together on redundant or single Modbus/TCP applications.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a EasyGen-3500XT-P2 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: EasyGen-3500XT-P2
  • SKU: EasyGen3500XTP2WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

EasyGen-3500XT-P2

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Woodward Inc's easYgen-3500XT-P2 Genset Controller is used for complex paralleling operations. The model can be used with several power generation topologies. The easYgen-3500XT-P2 model can be used with LS-6XT breaker models, 32 of the 3500XT-P2 models and 32 of the LS-6XT breakers can be used together on redundant or single Modbus/TCP applications.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a EasyGen-3500XT-P2 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: EasyGen-3500XT-P2
  • SKU: EasyGen3500XTP2WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

EasyGen-3500XT-P2 Technical Specifications

Ambient Humidity 95%, non-condensing
Max. power consumption per path < 0.15 W
Multi-lingual English, German, Spanish, French, Italian, Portuguese, Japanese, Chinese, Russian, Turkish, Polish, Slovakian, Finnish, Swedish
Protection System IP 20
Secondary Setting Range 1 - 32,000 A
Series 3000

Product Description

easYgen-3500XT-P2 is one of the newer models in Woodward’s easYgen-3000 series. The XT models have expanded features not included in earlier models, and there is slightly more variation between the Package 1 (P1) and Package 2 (P2) versions. This unit is a P2 model, so its capabilities are geared towards cogeneration/CHP and include expanded I/Os, 3-ph busbar voltage measurement, and an interface expansion card.



This genset control meets IP20 standards. It has a 12/24 VDC power supply and is intended for installation where temperatures will remain in the -20 to 70 °C range during operations (-30 to 80 °C for storage), with ambient humidity not to exceed 95% (non-condensing). easYgen model 3500XT-P2 has a 50/60 Hz measuring frequency, and a Class 0.5 accuracy rating.



Full connectivity of up to 32 gensets is provided with the easYgen-3500XT-P2 unit, as is standard for controllers in the easYgen-3000 series. Functions include load management capabilities such as:

  • Open / closed transition
  • Interchange
  • Load-dependent start/stop
  • Utility parallel

For redundancy, load share and device-to-device communication can happen over CAN and Ethernet.



easYgen-3500XT-P2 has four operation modes: Auto, Stop, Manual, and Test. Details on each of these modes, as well as configurable parameters of the unit, can be found in Woodward easYgen Manual 37528G and product spec sheet 37583.

  • 8440-2088
  • 8440-2089
Reviews For EasyGen-3500XT-P2
Internal Review

The easYgen-3500XT-P2 can be used in many different application topologies, one of these topologies is with this model and the GC-3000XT models. In the aforementioned application 496 Gensets, one generator group breaker, and one mains circuit breaker will be used. - AX Control Tech Team

Repair Services For EasyGen-3500XT-P2

Type Lead Time Price Action
Repair Service 1-2 weeks $884

Our highly skilled technicians can repair your EasyGen-3500XT-P2. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
