EasyGen-3400-5 Marine

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
Woodward EasyGen Controller Module easYgen-3400-5 Marine

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a EasyGen-3400-5 Marine to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: EasyGen-3400-5 Marine
  • SKU: EasyGen34005MarineWO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

EasyGen-3400-5 Marine

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
Woodward EasyGen Controller Module easYgen-3400-5 Marine

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a EasyGen-3400-5 Marine to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: EasyGen-3400-5 Marine
  • SKU: EasyGen34005MarineWO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

EasyGen-3400-5 Marine Technical Specifications

Ambient Humidity 95%, non-condensing
Analog Input Type 0-500Ohms/0-20 mA
Front Panel Dimensions 282W X 217H X 99D mm
Housing Connection screw/plug terminals 2.5 mm²
Intrinsic Consumption Max. 17 W
Primary Setting Range 50 - 650,000 Vac

Product Description

easYgen-3400-5 Marine

The Woodward series of EasyGen devices are a range of products that are designed to control several types of engines, turbines, and compressor units.This model is the easYgen-3400-5 Marine version. It features an exceptionally versatile range of hardware and abilities, with efficient flexibility. It allows the user to be centralized on a single, affordable control for many uses—from stand-alone emergency generators to the isochronous parallel operation of up to 32 gensets. The easYgen-3400-5 Marine can be configured for different application levels and responsibilities.

The easYgen-3400-5 Marine module is designed for multiple different configurations for a wide variety of applications. This unit is able to operate as a Load Share module, or as a Load Share module with synchronizer capabilities engaged. There is also a Load Share module, with an engaged synchronizer, with up to 16 external LS-5 breaker controls activated. The final available operational mode is with a Genset Control, with an additional, fully independent Start and Stop functions for auxiliary generators.

The easYgen-3400-5 Marine unit is built with individual configurable engine and generator protective features. These features include: Special Scania S6, MTU ADEC, Volvo EMS2 & EDC4, Deutz EMR2, MAN MFR/EDC7 and SaCos, CAT ADEM, SISU EEM, Cummins and Woodward E3 ECU support.

The Woodward EasyGen models are no longer covered by the original warranty, and our series of devices are protected by the comprehensive warranty for up to 1 to 3 years. Each of our units is a used piece of equipment, which is then refurbished and optimized.

  • 8440-2045
Reviews For EasyGen-3400-5 Marine
Internal Review

Genset controller model easYgen-3400-5 Marine has the ability to control up to sixteen LS-5 units which can also be used in conjunction with thirty-two easYgens in one application. - AX Control Technician

Repair Services For EasyGen-3400-5 Marine

Type Lead Time Price Action
Repair Service 1-2 weeks $895

Our highly skilled technicians can repair your EasyGen-3400-5 Marine. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
