Woodward INC easYgen-3400-1-P1 is a model that features breaker control such as slip frequency/phase matching synchronization and open-close control. This model also has the ability to provide connectivity of up to sixteen Woodward LS-5 Series controllers.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a EasyGen-3400-1-P1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: EasyGen-3400-1-P1
  • SKU: EasyGen34001P1WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

EasyGen-3400-1-P1

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
Woodward INC easYgen-3400-1-P1 is a model that features breaker control such as slip frequency/phase matching synchronization and open-close control. This model also has the ability to provide connectivity of up to sixteen Woodward LS-5 Series controllers.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a EasyGen-3400-1-P1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: EasyGen-3400-1-P1
  • SKU: EasyGen34001P1WO
  • Manufacturer: Woodward
  • Series: EasyGen-3000 Series

EasyGen-3400-1-P1 Technical Specifications

Accuracy Class 1
Ambient Humidity 95%, non-condensing
Analog Input Resolution 11 Bit
Measurable Alternator Windings 3p-3w, 3p-4w, 1p-2w, 1p-3w
Power Setting Range 0.5 - 99,999.9 kW/kvar
Power Supply 12/24 Vdc ( 8 to 40 Vdc)

Product Description

easYgen-3400-1-P1 is a Package 1 model in the Woodward easYgen-3000 series. The difference between P1 and P2 versions is primarily in the type and number of I/Os on this genset controller, including external analog inputs/outputs (CANopen) which are not included in the P2 models. Woodward easYgen-3000 manual 37523E has a full breakdown of the I/Os on this controller.



This easYgen model has the same versatility as the rest of the easYgen-3000 series, in its ability to control up to 32 connected gensets. easYgen-3400-1-P1 has the added capability to provide connectivity of up to 16 Woodward LS-5 Series controllers, a feature that makes this controller a suitable choice for applications with multiple bus tiebreakers and mains.



Since the easYgen-3400-1-P1 is intended for cabinet back mounting (the unit is in sheet metal housing) there is no built-in operator interface. Instead, this easYgen controller is managed via PC using Woodward’s ToolKit software. easYgen 3400 models are also pre-configured for connection with a Woodward Remote Display (RP-3000). If front panel mounting and a built-in HMI are required, see the 3500 easYgen models.

  • 8440-1956
  • 8440-1945
Reviews For EasyGen-3400-1-P1
Internal Review

EasyGen 3000 model easYgen-3400-1-P1 allows for the capability to provide full connectivity for potentially up to sixteen Woodward LS-5 Series controllers, which allow for complex power management applications with multiple bus tie breakers and mains. - AX Control Tech Team

Repair Services For EasyGen-3400-1-P1

Type Lead Time Price Action
Repair Service 1-2 weeks $841

Our highly skilled technicians can repair your EasyGen-3400-1-P1. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
